Heating & A/C
Refractory Paper
Ceramic High Temperature Twisted Rope
• Twisted three-ply rope made to meet tough industrial standards.
• Rated at 2300°F (1260°C).
• Asbestos free.
• Exhibits excellent chemical stability, resisting attack from most corrosive
agents (exceptions included hydrofluoric & phosphoric acids and
concentrated alkalies).
• Resist oxidation and reduction.
• Physical and thermal properties restored upon drying (if wet by water
or steam) - no water hydration present
Ceramic Rope
Part # Diameter
Carton
63-48200
1/4"
45'
63-48201
90'
63-48204
3/8"
25'
63-48205
50'
63-48208
1/2"
15'
63-48209
30'
63-58FR
5/8"
per foot
Refractory Paper
Part #
Description
63-48001
1/8" × 1' x 50' roll.
63-48002
1/8" × 2' x 50' roll.
63-48004
1/8" × 3' x 50' roll.
63-48006
1/8" × 4' × 50' roll.
Refractory Paper
• Commercial grade, low cost, high strength paper.
• Made from combination of ceramic fiber, inert fillers and fiberglass.
• For use up to 704°C (1300°F).
• Low shrinkage, good dielectric properties.
• Contains 6% organic binder for increased handling strength.
• Uniform structure assures equal thermal conductivity throughout and
provides a smooth surface - ideal for gasketing applications.
• Easy to handle and can be cut, wrapped and rolled to fit nearly any
configuration.
Fireplace & Wood
Burning Stove
Gaskets
Twisted Ceramic Rope
Applications
• Gasketing
• Packing
• Sealing
Make on the spot gaskets:
• Clean-outs
• Draft hoods
• Burner pouches
• Mounting flanges
• Cover gaskets and plates.
Refractory Boards
Refractory Fiber Insulation Boards
Ceramic fiber or mineral wool formed into rigid boards. Refractory
boards are famous for their low thermal conductivity and excellent
handling strength. Boards are easily machined, drilled, sawed, and
fabricated. Available in temperature 2300°F.
Refractory Fiber Insulation Boards
Part #
Thickness Length
Height
63-52436
1/2"
24"
36"
63-12436
1"
24"
36"
63-152436
1 1/2"
24"
36"
63-22436
2"
24"
36"
Applications
• Backup Insulation for Fiber
• Back up for Bricks or Castables
• Combustion Chamber Linings
• Gaskets & Seals
• Kiln & Stack Linings
• JewelrySoldering Boards
Ceramic Products
