281
Service Tools
•
Sensor Type
: State of the art CCD (Cold Cathode Diode Sensor) technology. Patented design
delivers quick and accurate response detection of refrigerant leaks while maintaining maximum
sensitivity throughout the life of the sensor. Detects all halogenated refrigerants, vapours &
gases. Highly resistant to background contaminants including heavy condensation, oils, leak
solutions brake oils, radiator coolants, washer fluids, etc...
•
Sensitivity
: Detects all refrigerants & blends (HFC) leaks small as a 7g (0.25 oz.) per year.
•
Audible Alarm
: Two pre-programmed & user-selectable alarm tones (HIGH & LOW intensity).
•
Visual Display
: - TACHOMETER bar graph display; 8 high intensity LEDs indicate refrigerant
intensity, pinpointing the exact location of a leak source.
- GEARSHIFT display; 7 high intensity LEDs indicate the current sensitivity range
of the unit and subsequent leak size.
* Gear 1 & 2 for small leaks.
* Gear 5 & 6 for large leaks.
* Gear 3 & 4 for medium leaks. * "N" (Neutral) unit is ready for operation.
•
One Button Operation
:
- Depress once to turn unit ON.
- Depress again to CLEAR the unit.
- Depress & hold to turn unit OFF.
- Double-click to change audible alarms tone.
•
Power
: 75 Hour battery life - Includes 3 "C" batteries (low battery indicator).
•
Auto OFF
: After 10 minutes of inactivity.
•
Flex Probe
: Flexible 35.5cm (14") long, 6.4mm (0.25") diameter.
•
Operating Temperature
: -18°C to 60°C (0°F to 140°F).
•
Weight
: Ergonomic Design! Single hand operation! 500g (1lb 2oz).
•
Warranty
: 2 year excluding sensors and batteries.
•
46-LS3000 Includes
:
- Spare CCD sensor (46-LSCS3)
- (3) size "C" alkaline batteries
- Instructions
- Durable plastic carrying case (46-LSXC3)
The Eliminator™
Exclusive Powershift™ - Fully automatic electronic refrigerant leak detector for all HFC,
HCFC, CFC, SF6 gases & blends. Exclusive POWERSHIFT software automatically
monitors, controls & adjusts all critical instrument settings to ensure maximum leak
search results under any job environment. Two separate visual LED displays enables
you to pinpoint the exact location of leak source & approximate size of that leak.
The Eliminator
Part #
Description
46-LS3000
Automatic Leak Detector
Automatic Refrigerant Leak Detector
46-LS3000
Illustrated
The Eliminator™ 46-LS3000
Part #
Description
46-LSXC3
Replacement carrying case.
46-LSXS3
1 sensor replacement.
Leak-Seeker® 46-LS780 & LS790 Series
Part #
Description
46-LSXBC
Battery compartment cover.
46-LSXC
Leatherette carrying case.
46-LSXE
Earphone.
46-LSXSF
Selective filter housing (46-LS780B & LS790B).
46-LSXSH
Aluminum sensor housing (46-LS780A & LS790A).
46-LSXS
Ion-pump sensor.
46-LSXVF
Water vapour filter (46-LS780A & LS790A).
46-LSXMK
(2) 46-LSXS sensors & (2) 46-LSXVF water vapour filters (46-LS780A & LS790A).
46-LSXBMK
(1) 46-LSXS sensor & (1) 46-LSXSF selective filter/ housing (46-LS780B & LS790B).
Leak Detector Parts & Accessories
46-LSXSF
Illustrated
46-LSXS3
Illustrated
High output alarm
speaker delivers clear
crisp alarm tones.
8 LED Tachometer Display
enables user to pinpoint
exact location of leak.
Leak Size: small,
medium & large.
Neutral: unit is
ready for operation.
Easy one button
operation: depress
once to turn ON,
press again to
CLEAR, double
click to change
audible alarm and
hold to turn OFF.
2 Year
Warranty!
State of the art cold
cathode diode (CCD)
sensor technology
Applications
• A/C & R
• Automotive
46-LSXS
Illustrated
Leak Detectors
