282
Service Tools
Refrigerant Gas Leak Detector
Refrigerant Leak Detection
• Detects all R134a, R12, R22 & alternative refrigerants.
• The most sensitive hand held leak detector on the market when
adjusted to MAX mode.
• Adjustable sensitivity levels.
• No calibration required.
• Long life sensor.
• Low battery indicator.
• Finds leaks in contaminated areas.
• Includes holster with belt clip.
Refrigerant Gas Leak Detector
Part #
Description
53-D340
Electronic leak detector.
•
Alarm Sensitivity
: 0.5 oz/yr. (R134a), 0.025 oz/yr. (R22)
•
Sensitivity
- Exceeds SAE standard J1627.
•
Operating Temperature Range
: 32°F to 105°F.
•
Power
: 4 AA batteries
•
Battery Life
: 8 to 10 continuous hrs with low battery indicator.
•
Warm Up
: < 60 seconds.
•
Operating Temperature
: -32°F to 104°F.
•
Probe Length
16.5".
•
Total Reach:
24".
•
Weight:
12.3 oz.
•
Warranty:
2 years.
53-D340
Illustrated
Applications
• Motor vehicle A/C
• Centrifugal chillers
• Refrigerant transport
• Industrial process
refrigeration.
• Industrial process air
conditioning
• Ice skating rinks
• Sold storage warehouses
• Heat transfer systems
• Household refrigerators,
freezers & A/C
• Reciprocating & screw
chillers
• Retail food refrigeration
• Ice machines
• Vending machines
• Water coolers
• Refrigerated transport
Professional Automotive Refrigerant Leak Detection
• Detects all CFC, HFC and HCFC refrigerants.
• Manual or automatic auto zero balance control.
• Unique sensor calibration system.
• Pinpoints both small and large leaks.
• Impact resistant, rugged case.
• Powered from external 12V DC source.
• Sensitivity ratings exceed SAE J1627.
Leak Detector - Automotive
Part #
Description
53-H10PA
• 12 V DC battery clamp adapter.
• Probe length 4.5'.
Electronic Leak Detector
53-H10PA
Illustrated
•
Sensor Type
- Positive ion emission heated diode.
•
Sensitivity
- Moving probe exceeds SAE standard J1627.
•
Alarm Sensitivity
: Detects all CFC, HRC and HCFC refrigerants:
- Small: 0.5 oz/yr. (R134a), 0.1 oz/yr. (R12)
- Medium: 1.0 oz/yr. (R134a), 0.5 oz/yr. (R12).
- Large: 5.0 oz/yr. (R134a), 3.0 oz/yr. (R12).
•
Leak Alarm
: Audible alarm and visible neon lamp.
•
Operating Temperature
: -32°F to 104°F.
•
Warranty
: Five year.
•
Dimensions:
5.5" × 10.5" × 8.5".
•
Weight:
3 lbs.
Automotive
Leak Detectors
