280
Service Tools
•
Sensor Type
- Patented ION-PUMP sensor for fast response time with built-in selective filter housing
to eliminate false alarms.
•
Sensitivity
: Detects all refrigerants & blends (HFC) leaks small as a 7g (0.25 oz.) per year.
•
Audible Alarm
: Over 100 computer generated tones varying in intensity with leak size.
•
Visual Display
: 10 visual LED leak size indicators.
•
LOCK-OUT Mode
: Unique feature enables quick & easy locating of refrigerant leaks in highly con-
taminated search zones. In this mode, the unit will automatically & systematically store the recorded
concentration levels of background refrigerants while initiating leak search, alarming only in the area
of the highest recorded concentration level, the actual leak source.
•
Power
: 40 Hour battery life - 4 "AA" batteries (low battery indicator).
•
Auto OFF
: After 15 minutes of inactivity.
•
Flex Probe
: Flexible 46cm (18") metal cable probe.
•
Operating Temperature
: -18°C to 60°C (0°F to 140°F).
•
Weight
: Single hand operation! 500g (1lb 2oz).
•
Warranty
: 2 year excluding sensors and batteries.
Leak-Seeker®
Combines the most advanced microcomputer circuitry with field proven ion-pump
technology creating a highly sensitive, accurate electronic leak detector. Over 100
computer generated tones and a high intensity bar graph display quickly alerts the
user to varying halogen concentrations. Patented automatic calibration eliminates the
need for manual balance or tick rate adjustments while a user selectable 10 sensitivity
ranges enables the 46-LS790B to detect leaks of all refrigerants.
Leak-Seeker®
With Lockout Mode & Bar Graph LED Display.
Part #
Description
46-LS790B
Electronic Leak Detector.
Electronic Leak Detector
46-LS790B
Illustrated
2 Year
Warranty!
Leak-Seeker®
Unique detection circuit design & patented ion-pump sensor technology combine to
create an accurate field reliable refrigerant leak detector that is easy to use. A rugged,
three position slide switch is used to turn the instrument ON and select either LO or
HIGH sensitivity ranges. Visual indication of the leak size is provided by a high intensity
LED varying in brightness with the concentration of the refrigerant detected.
•
Sensor Type
- Patented ION-PUMP sensor for fast response time with built-in selective filter housing
to eliminate false alarms.
•
Sensitivity
: Detects all refrigerants & blends (HFC) leaks small as a 7g (0.25 oz.) per year.
•
Audible Alarm
: Wide range audible alarm.
•
Visual Display
: High intensity LED.
• Simple HI/ LOW sensitivity setting operation.
•
Power
: 40 Hour battery life - 4 "AA" batteries (low battery indicator).
•
Auto OFF
: After 15 minutes of inactivity.
•
Flex Probe
: Flexible 36cm (14 1⁄4") metal cable probe.
•
Operating Temperature
: -18°C to 60°C (0°F to 140°F).
•
Weight
: Single hand operation! 500g (1lb 2oz).
•
Warranty
: 1 year excluding sensors and batteries.
Leak-Seeker®
Part #
Description
46-LS780B
Electronic Leak Detector.
Electronic Leak Detector
46-LS780B
Illustrated
1Year
Warranty!
Leak Detectors
