109
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from
hub face to shaft end
OEM
OEM Replacement Motors
OEM Replacement Motors
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
T2535
3/4
1/1140
575
1.40
Rev
3 Ph 6.5"
8.10"
3.0"×5/8"
1C16992P1
1
T2531
3/4
1/1100
208/230
460
4.00
Rev
3 Ph 6.5"
8.10
3.0"×5/8"
1C16992P1
1
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R465
1/15
3/1550
115
2.25 CCW SP 3.3"
4.00" 2.3"×5/16"×2.3
23202
2
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R213
1/25
1/1550
115
1.40 CCW SP 3.3"
3.10"
1.7"×5/16"
CM88953
3
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
S1100
1/3
1/1625
115
3.80
Rev PSC/INC 5.5"
8.50"
1.9"×5/8"
Louver Fans
4
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R2691
1/5
1/1075 208/230 1.50
CW 5/370 5.0"
4.00"
3.9"×1/2"
35035B001
5
Liebert
Life Breath - Nutech
Lincoln
Lord Burnham
Magic Chef
Fig.1
Fig.4
Fig.5
Fig.2
Fig.3
