Butt’s Pumps and Motors - page 1601

110
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from
hub face to shaft end
OEM
OEM Replacement Motors
OEM Replacement Motors
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R350
1/55
2/1050
115
1.20
CW SP 3.3"
2.85"
1.5"×5/16"
5AA1A3-P4S
4
R133
1/40
2/1550
115
1.00 CCW SP 3.3"
2.60"
-
5DH1A1-P456
5
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R52430
1/4
3/1060 208/230 1.50
CW 3/370 5.5"
4.50" 4.1"×1/2"×4.7" 24303, KCP39KGV3735 6
R10810
1/3
1/1625 208/230 2.70
CW 3/370 5.5"
4.50"
7.5"×1/2"
10810, CP39GG1964BS 7
Mark Hot
Majestic
McQuay Remington
Fig.1
Fig.2
Fig.3
Fig.4
Fig.6
Fig.5
Fig.7
Part # Watts Spd/RPM Volts Amps Rot
Type Dia
Body
Shaft
Comment
Fig
RB12
50
1/1250
115
0.86
CW SP Skel
12.9"×4.3"×3.6"
-
FK12
1
RB64
50
1/1200
115
0.86
CW SP Skel
12.9"×4.3"×3.6"
-
FA20, FK24, RHE32,
18L46, HE30, HE32
1
RB65
50
1/1250
115
0.86
CW SP Skel
12.9"×4.3"×3.6"
-
FK24, 33DBVRRN,
DBT33, 36, 39,
DBR33, 36, 39
2
RB63
50
1/1250
115
0.86
CW SP Skel
12.9"×4.3"×3.6"
-
RB65 blower & base only 2
RB130
53
1/2800
115
0.92
CW SP Skel
8"×4.56"×4.32"
-
FK30, 52425
3
