Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from
hub face to shaft end
OEM
OEM Replacement Motors
OEM Replacement Motors
Fig.3
Fig.1
Fig.4
Fig.2
Fig.5
Fig.6
Fig.7
Fig.8
Part #
HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R701
1/12
1/1550
115
1.30 CCW
PSC/INC
3.3"
4.60" 5.0"×5/16"×2.7"
202807, SM720
1
RFM9
1/12
1/3000 208/230 1.10 CCW SP 3.3"
6.40"
2.8"×5/16"
501493
2
R22576
1/9
2/1060 208/230 0.60
CW
3/370
5.5"
3.80"
2.3"×1/2"
128576
3
R2423
1/8
3/1330
115
1.80
CW
10/370
5.0"
3.40" 5.0"×1/2"×2.0"
200423, R780
3
R780
1/8
3/1330
115
1.70
CW
10/370
5.5"
3.50" 2.4"×1/2"×5.1"
200423, 71213, 71924, 71925,
88425, 88898, 89395, SM711 4
R785
1/6
1/1060 208/230 0.90
CW 3/370 5.5"
3.30"
2.3"×1/2"
128577
3
R30575
1/6
1/1625
575
0.50
Rev PSC/INC 5.5"
4.50"
2.2"×1/2"
1042401
5
R31672
1/6
2/1075 208/230 1.50
CW
7.5/370
5.5"
4.00"
3.5"×1/2"
171672, 120240
6
R30409
1/5
1/1550 208/230 1.80 CCW 4/370 5.5"
4.60"
3.0"×1/2"
120409, 1041300
7
R31065
1/5
1/1140
575
0.50
Rev
3 Ph 5.5"
6.30"
2.8"×5/8"
171065
6
R30900
1/2
1/1075 208/230 2.30
CW
7.5/370
5.5"
5.25"
4.0"×5/8"
510900
7
T1536
3/4
1/1140
575
1.50
Rev
3 Ph 5.5" 11.00"
4.0"×5/8"
106670
8
R42464
1
3/1075
208/230
460
5.40
R.P.
12.5/370
5.5"
6.50"
3.5"×5/8"
504464
7
T2538
1
3/1140
208/230
460
4.00
Rev
3 Ph 6.5"
9.10"
5.0"×5/8"
170518, 502595
7
T2540
1
1/1140
575
2.30
Rev
3 Ph 6.5"
9.10"
5.0"×5/8"
170517, KPN502597 7
T1826
1¼
1/1100 208/230 5.00
Rev
3 Ph 6.5"
9.50"
3.0"×5/8"
1043297-001
9
T1946
1¼
1/1100
575
2.00
Rev
3 Ph 6.5"
9.50"
3.0"×5/8"
1043299-001
9
S1454
1¾
1/1075 208/230 5.50
Rev
20/370
6.5" 10.50"
6.0"×5/8"
170619
7
Keeprite ( ICP ) -
continued from previous
