OEM Replacement Motors
OEM Replacement Motors
Ideal
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R611
1/300
1/1550
115
0.54
CW SP Skel
0.50"
2.2"×.181"
Evaporator Motor
1
R108
1/100
1/1550
115
0.55 CCW SP 3.3"
1.94" 0.7" huBLESS Evaporator Motor
2
R123
1/50
1/1550
115
0.60
CW SP 3.3"
2.44" 0.6" HUBLESS Evaporator Motor
2
R126
1/50
1/1550
115
0.75
CW SP 3.3"
2.44" 0.8" HUBLESS Evaporator Motor
3
Fig.2
Fig.5
Fig.6
Fig.4
Fig.3
Fig.1
Intercity
Jennair
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R2609
1/30
1/1550
115
1.21
CW SP 4.1"
3.00"
2.4"×1/2"
UE009
4
R2612
1/30
1/1550
115
1.21 CCW SP 4.1"
3.00"
2.4"×1/2"
UE2612
4
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
RFB500
1/30
1/2860
115
1.10 CCW SP 3.3"
5.50"
-
FASCO D500
6
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
RFB6
1/60
1/3000
230
0.55
CW SP 3.3"
6.10"
-
3855C1, 3855C3,
8973C1, 80280
5
Johnson, Airease, Magic Chef Furnace
