Butt’s Pumps and Motors - page 1602

111
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from
hub face to shaft end
OEM
OEM Replacement Motors
OEM Replacement Motors
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R206
1/80
2/1550
115
0.56
CW SP 3.3"
2.09"
1.4"×1/4"
Vent Fan
1
R203
1/70
1/1550
115
0.80 CCW SP 3.3"
2.10"
1.5"×1/4"
1V2430
2
R214
1/50
1/2700
115
0.76
CW SP 3.3"
2.80"
1.5"×1/4"
Vent Fan
1
R200
1/50
2/3000
115
1.00 CCW SP 3.3"
2.60"
1.2"×1/4"
Vent Fan
1
R610
1/50
1/2400
115
1.00
CW SP Skel
0.90"
1.2"×7/32"
1V4217
3
R209
1/45
1/1550
115
0.87
CW SP 3.3"
2.30"
1.5"×5/16"
1V3117, 39328
1
R220
1/20
1/1550
115
1.60 CCW SP 3.3"
2.80"
1.2"×5/16"
1V2429
1
Miami Carey
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R2326
1/7
1/1050
115
4.70 CCW SP 5.0"
3.30"
3.0"×1/2"
U.E. 326
4
R2393
1/5
1/1050
115
6.00 CCW SP 5.0"
3.80"
5.8"×1/2"
OML6433
5
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
RF100-2
1/167
2/3000
115 0.50 CCW SP Skel
2.75"
-
2811-581-001, EF100,
RF100, 2811-581-002,
EF100-2
6
Miller Furnace
Montego, Selkirk
Fig.2
Fig.1
Fig.3
Fig.4
Fig.5
Fig.6
Moyer & Diebel
Fig.8
Fig.7
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R320
1/100
1/1550
115
0.47
CW SP 3.3"
2.10"
1.3"×1/4"
EM12
7
R307
1/30
1/3000
115
1.10 CCW SP 3.3"
3.30"
1.3"×1/4"
Furnace Blower
8
