Submersible Non-Clog Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598 A Crane Co. Company
16
C
www.cranepumps.com
Professional Plumbing
Series 2SEV-DS
2" Spherical Solids Handling
Vortex, Double Seal
4/04
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION II HAZARDOUS LOCATIONS.
3.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION I HAZARDOUS LOCATIONS.
4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
inches
(mm)
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
2SEV514DS 104923 0.5 120/1 60 1750 F 12.0 21.3 14/3 SJTOW 0.375 (9.5)
2SEV524DS 104924 0.5 240/1 60 1750 J 6.3 14.9 14/3 SOW 0.530 (13.5)
2SEV594DS 104925 0.5 200-240/3 60 1750 H/L 3.7/3.8 9.8/11.0 14/4 SOW 0.570 (14.5)
2SEV544DS 104926 0.5 480/3 60 1750 K 1.9 5.3 14/4 SOW 0.570 (14.5)
2SEV554DS 104927 0.5 600/3 60 1750 H 1.4 3.4 14/4 SOW 0.570 (14.5)
2SEV724DS 104932 0.75 240/1 60 1750 K 7.1 25.8 14/3 SOW 0.530 (13.5)
2SEV794DS 104933 0.75 200-240/3 60 1750 H/K 4.8/4.6 13.7/15.4 14/4 SOW 0.570 (14.5)
2SEV744DS 104934 0.75 480/3 60 1750 K 2.3 7.7 14/4 SOW 0.570 (14.5)
2SEV754DS 104935 0.75 600/3 60 1750 L 1.6 7.2 14/4 SOW 0.570 (14.5)
2SEV1024DS 104940 1.0 240/1 60 1750 G 8.5 25.8 14/3 SOW 0.530 (13.5)
2SEV1094DS 104941 1.0 200-240/3 60 1750 E/H 5.3/5.1 13.7/15.4 14/3 SOW 0.570 (14.5)
2SEV1044DS 104942 1.0 480/3 60 1750 H 2.5 7.7 14/4 SOW 0.570 (14.5)
2SEV1054DS 104943 1.0 600/3 60 1750 J 2.2 7.2 14/4 SOW 0.570 (14.5)
OPTIONAL - Temperature sensor cord for 3 phase models is 14/3 SOW, 0.530 (13.5mm) O.D.
OPTIONAL - Moisture sensor cord is 18/5 SOW, 0.470 (11.9mm) O.D.
OPTIONAL - Moisture & Temperature sensor cord for 3 phase models is 18/5 SOW, 0.470 (11.9mm) O.D.
