SECTION
PAGE
DATE
Submersible Non-Clog Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598 A Crane Co. Company
26
C
www.cranepumps.com
Professional Plumbing
Series 3SE-L
1½" Spherical Solids Handling
Single Seal
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION 2 HAZARDOUS LOCATIONS.
3.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION 1 HAZARDOUS LOCATIONS.
4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
inches
(mm)
7/12
MODEL NO PART
NO
HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
3SE1522L 132775 1.5 230/1 60 3450 A 12.0 31.0 12/3 SOOW/SOW 0.61 (15.5)
3SE1592L 132842 1.5 200-230/3 60 3450 C/F 9.8/8.6 31.3/36.0 12/4 SOOW/SOW 0.68 (17.3)
3SE1542L 132844 1.5 460/3 60 3450 F 4.3 18.0 14/4 SOOW/SOW 0.57 (14.5)
3SE1552L 132846 1.5 575/3 60 3450 F 3.4 14.4 14/4 SOOW/SOW 0.57 (14.5)
3SE2022L 132848 2.0 230/1 60 3450 A 13.5 31.0 12/3 SOOW/SOW 0.61 (15.5)
3SE2092L 132850 2.0 200-230/3 60 3450 A/C 11.5/10.0 31.3/36.0 12/4 SOOW/SOW 0.68 (17.3)
3SE2042L 132852 2.0 460/3 60 3450 C 5.0 18.0 14/4 SOOW/SOW 0.57 (14.5)
3SE2052L 132854 2.0 575/3 60 3450 C 4.0 14.4 14/4 SOOW/SOW 0.57 (14.5)
OPTIONAL - Temperature sensor cord for 3 phase models are 14-3 / 18-5 SOOW / SOW, 0.53 (13.5mm) / 0.47 (11.9mm) O.D.
