SECTION
PAGE
DATE
Submersible Non-Clog Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598 A Crane Co. Company
20
C
www.cranepumps.com
Professional Plumbing
4/04
inches
(mm)
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION II HAZARDOUS LOCATIONS.
3.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION I HAZARDOUS LOCATIONS.
4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
2SEV512DS* 104976 0.5 120/1 60 3450 G 12.6 24.6 14/3 SJTOW 0.375 (9.5)
2SEV522DS 104977 0.5 240/1 60 3450 E 6.0 10.2 14/3 SOW 0.530 (13.5)
2SEV1022DS 104987 1.0 240/1 60 3450 F 10.7 21.8 14/3 SOW 0.530 (13.5)
2SEV1092DS 104988 1.0 200-240/3 60 3450 H/J 7.9/7.5 19.9/18.4 14/4 SOW 0.570 (14.5)
2SEV1042DS 104990 1.0 480/3 60 3450 J 3.7 9.1 14/4 SOW 0.570 (14.5)
2SEV1052DS 104991 1.0 600/3 60 3450 L 2.9 8.7 14/4 SOW 0.570 (14.5)
OPTIONAL - Temperature sensor cord for 3 phase models is 14/3 SOW, 0.530 (13.5mm) O.D.
OPTIONAL - Moisture sensor cord is 18/5 SOW, 0.470 (11.9mm) O.D.
OPTIONAL - Moisture & Temperature sensor cord for 3 phase models is 18/5 SOW, 0.470 (11.9mm) O.D.
(*) Pump is CSA listed ONLY.
Series 2SEV-DS
2" Spherical Solids Handling
Vortex, Double Seal
