Submersible Non-Clog Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598 A Crane Co. Company
22
C
www.cranepumps.com
Professional Plumbing
Series 2SEV-L
2" Spherical Solids Handling
Vortex, Single Seal
4/04
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION II HAZARDOUS LOCATIONS.
3.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION I HAZARDOUS LOCATIONS.
4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
inches
(mm)
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
2SEV1522L 104187 1.5 240/1 60 3450 A 13.5 31.5 12/3 SOW 0.610 (15.5)
2SEV1592L 104188 1.5 200/240/3 60 3450 C 10.8/9.8 27.0 14/4 SOW 0.600 (15.2)
2SEV1542L 104189 1.5 480/3 60 3450 F 4.9 13.5 14/4 SOW 0.600 (15.2)
2SEV1552L 105774 1.5 600/3 60 3450 F 3.9 11.0 14/4 SOW 0.600 (15.2)
2SEV2022L 104190 2.0 240/1 60 3450 C 16.0 42.0 12/3 SOW 0.610 (15.5)
2SEV2092L 104191 2.0 200/240/3 60 3450 J 13.2/12.0 30.0 14/4 SOW 0.600 (15.2)
2SEV2042L 104192 2.0 480/3 60 3450 J 6.0 15.0 14/4 SOW 0.600 (15.2)
2SEV2052L 105775 2.0 600/3 60 3450 J 4.8 12.0 14/4 SOW 0.600 (15.2)
OPTIONAL - Temperature sensor cord for 3 phase models is 14/3 SOW, 0.530 (13.5mm) O.D.
