Submersible Non-Clog Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
40
C
Professional Plumbing
Series
3SE-DS
2½" Spherical Solids Handling
Double Seal
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION 2 HAZARDOUS LOCATIONS.
3.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION 1 HAZARDOUS LOCATIONS.
4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
inches
(mm)
7/12
MODEL
NO
PART
NO
HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
3SE1524DS 132745 1.5
230/1 60 1750
C 16.0
44.6
12/3 SOOW / SOW 0.610 (15.5)
3SE1594DS 132758 1.5 200-230/3 60 1750 D/G 13.3/11.6 35.8/41.2 12/4 SOOW / SOW 0.680 (17.4)
3SE1544DS 132760 1.5
460/3 60 1750
G 5.8
20.6
14/4 SOOW / SOW 0.570 (14.5)
3SE1554DS 132761 1.5
575/3 60 1750
G 4.6
16.4
14/4 SOOW / SOW 0.570 (14.5)
3SE2024DS 132765 2.0
230/1 60 1750
A
19.0
44.6
10/3 SOOW / SOW 0.660 (16.8)
3SE2094DS 132768 2.0 200-230/3 60 1750 B/D 15.2/13.2 35.8/41.2 12/4 SOOW / SOW 0.680 (17.4)
3SE2044DS 132770 2.0
460/3 60 1750
D
6.6
20.6
14/4 SOOW / SOW 0.570 (14.5)
3SE2054DS 132772 2.0
575/3 60 1750
D
5.2
16.4
14/4 SOOW / SOW 0.570 (14.5)
Moisture & Temperature sensor cord for all models is 18/5 SOOW/SOW, 0.47 (11.9mm) O.D.
OPTIONAL Temperature only sensor cord for 3 phase models is 14/3 SOOW/SOW, 0.53 (13.5mm) O.D.
