Submersible Non-Clog Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598 A Crane Co. Company
34
C
www.cranepumps.com
Professional Plumbing
Series 3SE-L
2½" Spherical Solids Handling
Single Seal
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION 2 HAZARDOUS LOCATIONS.
3.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION 1 HAZARDOUS LOCATIONS.
4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
inches
(mm)
7/12
MODEL NO PART
NO
HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
3SE1524L 132725 1.5 230/1 60 1750 C 16.0 44.6 12/3 SOOW/SOW 0.610 (15.5)
3SE1594L 132730 1.5 200-230/3 60 1750 D/G 13.3/11.6 35.8/41.2 12/4 SOOW/SOW 0.680 (17.4)
3SE1544L 132735 1.5 460/3 60 1750 G 5.8 20.6 14/4 SOOW/SOW 0.570 (14.5)
3SE1554L 132740 1.5 575/3 60 1750 G 4.6 16.4 14/4 SOOW/SOW 0.570 (14.5)
3SE2024L 132750 2.0 230/1 60 1750 A 19.0 44.6 10/3 SOOW/SOW 0.660 (16.8)
3SE2094L 132752 2.0 200-230/3 60 1750 B/D 15.2/13.2 35.8/41.2 12/4 SOOW/SOW 0.680 (17.4)
3SE2044L 132754 2.0 460/3 60 1750 D 6.6 20.6 14/4 SOOW/SOW 0.570 (14.5)
3SE2054L 132756 2.0 575/3 60 1750 D 5.2 16.4 14/4 SOOW/SOW 0.570 (14.5)
Optional - Temperature Sensor Cord for 3 Phase models are 14/3 & 18/5. SOOW / SOW, 0.530 (13.5mm) / 0.470 (11.9mm) O.D.
