Submersible Non-Clog Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
32
C
Professional Plumbing
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION II HAZARDOUS LOCATIONS.
3.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION I HAZARDOUS LOCATIONS.
4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
inches
(mm)
4/04
Series
3SE-DS
2" Spherical Solids Handling
Double Seal
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
3SE514DS
104897 0.5
120/1
60 1750
F
11.6
21.3
14/3 SJTOW 0.375 (9.5)
3SE524DS
104898 0.5
240/1
60 1750
J
5.9
14.9
14/3 SOW 0.530 (13.5)
3SE594DS
104899 0.5 200-240/3 60 1750 H/L 3.2/3.0 9.8/11.0 14/4 SOW 0.570 (14.5)
3SE544DS
104900 0.5
480/3
60 1750
K
1.5
5.3
14/4 SOW 0.570 (14.5)
3SE554DS
104901 0.5
600/3
60 1750
H
1.0
3.4
14/4 SOW 0.570 (14.5)
3SE774DS
104906 0.75 200-240/1 60 1750 G/K 7.4/7.0 21.5/25.8 14/3 SOW 0.530 (13.5)
3SE794DS
104907 0.75 200-240/3 60 1750 H/K 4.8/4.5 13.7/15.4 14/4 SOW 0.570 (14.5)
3SE744DS
104908 0.75
480/3
60 1750
K
2.2
7.7
14/4 SOW 0.570 (14.5)
3SE754DS
104909 0.75
600/3
60 1750
L
1.5
7.2
14/4 SOW 0.570 (14.5)
3SE1074DS
104914 1.0 200-240/1 60 1750 D/G 8.8/8.3 21.5/25.8 14/3 SOW 0.530 (13.5)
3SE1094DS
104915 1.0 200-240/3 60 1750 E/H 5.14/4.9 13.7/15.4 14/3 SOW 0.570 (14.5)
3SE1044DS
104916 1.0
480/3
60 1750
H
2.4
7.7
14/4 SOW 0.570 (14.5)
3SE1054DS
104917 1.0
600/3
60 1750
J
1.9
7.2
14/4 SOW 0.570 (14.5)
OPTIONAL - Temperature sensor cord for 3 phase models is 14/3 SOW, 0.530 (13.5mm) O.D.
OPTIONAL - Moisture sensor cord is 18/5 SOW, 0.470 (11.9mm) O.D.
OPTIONAL - Moisture & Temperature sensor cord for 3 phase models is 18/5 SOW, 0.470 (11.9mm) O.D.
