SECTION
PAGE
DATE
Submersible Non-Clog Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
36
C
Professional Plumbing
Series
3SE-L
2½" Spherical Solids Handling
Single Seal
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION 2 HAZARDOUS LOCATIONS.
3.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION 1 HAZARDOUS LOCATIONS.
4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
inches
(mm)
7/12
24.38
(619)
9.60
(244)
3.00 N.P.T
DISCHARGE
8.25
(210)
14.56
(370)
2.15
(55)
12.63
(321)
6.32
(161)
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
3SE3024L
133115 3.0
230/1 60 1750
A
28.0
59.0
10/3 SOOW/SOW .66 (16.8)
3SE3034L
133116 3.0
230/3 60 1750
D 19.0
56.0
12/4 SOOW/SOW .68 (17.4)
3SE3044L
133117 3.0
460/3 60 1750
D
9.0
28.0
14/4 SOOW/SOW .57 (14.5)
3SE3054L
133118 3.0
575/3 60 1750
E
8.3
23.0
14/4 SOOW/SOW .57 (14.5)
OPTIONAL - Temperature sensor cord for 3 phase models is 18/5 SOOW/SOW, 0.470 (11.9mm) O.D.
