0.25/
1
/
3
1425 S56
102183
19 220/380-440
1.10 65.0 10.31
0.37/
1
/
2
1425 56
114304
L
25 220/380-440
1.02 78.0 10.38
0.55/
3
/
4
2850 56
114306
24 220/380-440
1.75 70.0 10.81
1425 56
114307
27 220/380-440
1.85 74.0 11.31
0.75/1
2850 56
114308
26 220/380-440
2.40 71.0 11.31
1425 56
114888
28 220/380-440
2.00 77.0 11.31
1425 143T
121096
35 220/380-440
2.00 77.0 12.75
1.1/1
1
/
2
2850 145T
121097
34 220/380-440
2.90 80.0 12.76
1425 145T
121093
40 220/380-440
3.30 75.5 12.75
1.5/2
2850 145T
121094
42 220/380-440
3.60 80.0 12.75
1425 145T
121095
40 220/380-440
3.65 81.5 13.25
2.2/3
2850 182T
131480
58 220/380-440
4.80 82.5 13.46
1425 182T
131459
64 220/380-440
4.70 84.0 13.46
3.7/5
2850 184T
131481
76 220/380-440
7.40 84.0 14.46
1425 184T
131454
87 220/380-440
8.10 85.0 15.47
L
4HESE MOTORS ARE TOTALLY ENCLOSED NON VENTILATED )%# COOLING METHOD )#
xäÊ ,/<Ê "/",-
THREE PHASE
xäÊ <ÊUÊ/ , Ê* -
General Specifications:
Totally enclosed fan cooled,
12-lead motors designed
specifically for 50 Hz service.
These motors are intended for
equipment built in North America
and destined for use in 50 Hz
service areas of the world.
Features:
These NEMA frame motors are
designed to North American
performance standards, but for 50 Hz service. Suitable for 220/380
volt, 50 Hz, or 440 volt, 50 Hz, three phase power. Torques
EXCEED .%-! PERFORMANCE STANDARDS FOR $ESIGN " MOTORS AND
produce the full rated horsepower at 50 Hz speeds.
#ONSTRUCTION MEETS )%# )0 DEGREE OF PROTECTION STANDARDS AND
UTILIZES EXTERNAL FAN COOLING )%# COOLING METHOD )# 'ASKETED
conduit box is in the North American standardized F1 location, with
leads.
xäÊ <Ê*"7 ,Ê- ,6 ÊUÊ/ , Ê
* - Ê, , / Ê
-Ê ",ÊÈäÊ <Ê
MOTORS
LEESON THREE PHASE
60 Hz WATTSAVER
®
motors are
satisfactory for operation on 50 Hz power supplies at full rated
horsepower with no derating required. Durable self-adhesive
labels are available from your LEESON District Office for
affixing to the motors, if desired. These labels state the motor
is satisfactory for operation on 50 Hz. The speed of the motors
on 50 Hz will be approximately 5/6 of the 60 Hz speed noted
in this catalogue.
2EQUEST LABEL
4HIS LABEL SIGNIFIES THE MOTOR IS
satisfactory for 50 Hz voltages of 190-200-208-220 volts
when the “low voltage” connection is made. For the “high
voltage”connection the motor is satisfactory for operation on
380-400-416-440 volts, 50 Hz.
Other three phase motors may be operable at 50 Hz at 5/6ths of
60 Hz horsepower and speed. Check with LEESON to verify that
the motor is satisfactory for derated operation on 190-200-208
volts using the “low voltage” connection or 380-400-416 volts
USING THE hHIGH VOLTAGEv CONNECTION AS SHOWN ON LABEL
Applies only to steel frame motors.
LEESON
50 Hz Voltages On
50/60 Designs
60 Hz
50 Hz
230V
190V
200V
208V
220V
460V
380V
400V
416V
440V
Request label No. 004060
LEESON
Three Phase Motor — 50 Hz Operation
This motor will operate at 60 Hz torque on
50 Hz, 1.0 service factor at the following voltages:
60 Hz
50 Hz
Nameplate Voltage
Voltage
230V
190-200-208V
460V
380-400-416V
Request label No. 004158
