Gearmotors
Catalogue
For Motor
DIMENSIONS (Inches)
Number
Frames
A
B
C
K
M1760000*
25
2.09
2.45
2.23
0.875
M1760021
*
30/31
3.13
2.63
2.28
0.875
M1760007
34
3.13
2.63
2.28
0.875
M1760012
38
4.75
2.75
2.00
1.125
175893
42
4.75
2.75
2.00
1.125
Note:
*
For any gearmotor catalogue number beginning with M1115XXX,
must clarify from gearmotor type and frame columns. For example, if
gearmotor type and frame lists P303-30E, then use 30 frame conduit
box kit M1760021. If gearmotor type and frame lists 10F60-25, then
use conduit box kit M1760000.
Catalogue
For
DIMENSIONS (Inches)
Number
Motors
A
B
C
1
D
1
1
D
2
1
D
3
X
BA
F
E
M1760003
* PZ Gearmotors
3.75 4.50 3.935 3.00 2.25
1.50 2.645 1.50 1.875 3.75
M1760011
** PE350 Gearmotors 4.50 6.00 5.520 4.00 3.10
2.20 3.625 1.50 2.500 5.00
M1760029
$
PE350 Gearmotors 4.50 6.00 5.520 4.00 3.10 2.20 3.625 1.50 2.500 5.00
* Maximum radial load no greater than 50 lbs. This bracket can also be used on DC motors in the 34 frame having the style C mounting.
**Maximum radial load no greater than 200 lbs.
$
Washguard PE350 L-Bracket
Catalogue
Number
M1760006
CAPACITORS
FOR SUB-FHP AC PZ SERIES GEARMOTORS
MFD
Voltage
Catalogue
DIMENSIONS (Inches)
Rating
Rating
Number
W
H
T
D
3.0
250
003043.01
1.22
0.93
0.57
0.97
10.0
250
003043.05
1.89
1.14
0.75
1.14
CAPACITORS
FOR SUB-FHP RIGHT-ANGLE AC GEARMOTORS
MFD
Voltage
Catalogue
DIMENSIONS (Inches)
Rating
Rating
Number
W
H
T
D
10.0
250
003043.05
1.89
1.14
0.75
1.14
15.0
300
003042.05
2.28
1.61
1.14
2.48
CAPACITORS
FOR SUB-FHP P240 & PE350 AC GEARMOTORS
Gearmotor
MFD
Voltage
Catalogue
DIMENSIONS (Inches)
Type
Rating
Rating
Number
W
H
T
D
P240
7.5
250
003042.02
1.89
1.14
0.75
1.14
PE350
10.0
250
003042.06
1.89
1.24
0.89
2.11
P240
15.0
300
003042.05
2.28
1.61
1.14
2.48
PE350
15.0
250
003042.04
2.28
1.46
0.93
2.33
SUB-FHP ACCESSORIES
FIELD INSTALLED
SUB-FHP GEARMOTOR RIGHT-ANGLE BASE KIT
This Optional Base Kit can be used with the 10 Series right-angle gearmotors.
(Includes screws for mounting to gearbox, but not the application.)
SUB-FHP GEARMOTOR
CONDUIT BOXES
Optional steel conduit or junction boxes are
available. The boxes are painted and mount
in holes using screws provided with all stock
gearmotors.
M1760000
M1760007
&
M1760021
M1760008
&
175709
M1760012
&
175893
SUB-FHP GEARMOTOR “L”
MOUNTING BRACKET
Optional “L” brackets can be used to mount parallel
shaft type PZ or PE350 gearmotors. Of steel
construction, they are painted and include screws
for mounting to the motor, but not the application.
