Butt’s Pumps and Motors - page 588

Gearing
ELECTRA-GEAR
Horizontal Base
Worm Under
Modified Stock Styles
Style TMQ
Style TM
Style T
Style UMQ*
Style UM*
Style U*
*
Not a recommended mounting style. Contact Factory for selection assistance.
Horizontal Base
Worm Over
5SING OFF THE SHELF ACCESSORIES STOCK STYLES "-1 "- AND " CAN BE FIELD OR
&ACTORY MODIFIED INTO A WIDE RANGE OF STYLES 3EE CATALOGUE FOR DETAILS
Style BMQ
Style BM
Style B
Stock Styles
CAST IRON
SOLID SHAFT OUTPUT STYLES
NON-
FLANGED
INPUT
MOTORIZED
C-FLANGE
FLEXIBLE
COUPLING
INPUT
MOTORIZED
C-FLANGE
QUILL
INPUT
Additional accessories, options and assembly services are available,
contact Factory for details.
Horizontal Base
Worm Center
Style RMQ
Style RM
Style R
Vertical
Input Shaft
Style JMQ
Style JM
Style J
ASK FOR CATALOGUE 8050 FOR MANY MORE STYLES
Specifications are subject to change without notice
