Specifications are subject to change without notice
Controls
Catalogue
Description
Number
Cable Sleeve Style
2 Button - 1 NO - All Single Speed
P02.1
2 Button - 2 NO - All Single Speed
P02.2
2 Button - 2 NO - All Two Speed
P02.D2
P02 Series stations have directional arrow type legend plates.
173
PENDANT STATIONS
HAND-HELD PUSHBUTTON MODULES
PENDANT STATIONS
These pendant stations are designed for heavy duty
hoist and crane applications. They employ a rugged
lightweight double-insulated thermoplastic enclosure
designed for easy handling and simple operation.
The standard units shown are available from stock
and are complete with standard nameplates, booted
pushbuttons and contact blocks.
All button pairs are mechanically interlocked. All
buttons are momentary.
Many custom variations are available and can be
assembled quickly from stock components. Consult
,%%3/. FOR DETAILS
PENDANT STATIONS FEATURE:
s 2UGGED HIGH IMPACT CORROSION AND CHEMICAL
resistant thermoplastic enclosure
s 3TAINLESS STEEL SCREWS
s #ONTACT BLOCKS HAVE STANDARD DOUBLE BREAK
self-cleaning, silver contacts
s #HEMICAL RESISTANT NEOPRENE GASKETS CABLE
sleeves and pushbutton glands.
s -ECHANICAL INTERLOCK STANDARD ON
speed pairs.
s (EAVY DUTY STEEL HANGER ALLOWS EASY INSTALLATION OF
strain relief cable.
s 4APERED ROUND CABLE ENTRY SLEEVE CAN BE CUT TO
MATCH CABLE DIAMETER ,ARGE INTERNAL PLASTIC CLAMP
tightens the cable firmly in the enclosure housing
s (IGH VISIBILITY BRIGHT YELLOW FINISH
s %ASY TO READ NAMEPLATES OR DIRECTIONAL ARROWS
s 3IMPLIFIED FIELD WIRING !LL BUTTONS CONTACT BLOCKS
strain relief block, and cable entrance are mounted
in the upper 1/2 of the station. To wire the station,
simply remove the lower cover to expose the
contact blocks, and cable entrance opening. The
cover screws are self retained in the lower cover.
Pull the entrance cable through the cable
sleeve, attach the cable wires to the
contact blocks, position the cable wires, and then
attach the lower cover to the station.
s 490% 8 )0 RATED ENCLOSURE
OPTIONS FOR P03 & PL SERIES
s h3.!0 /.v
SPEED CONTACT BLOCKS
s +NOB TYPE SELECTOR SWITCH
s +EYED SELECTOR SWITCH
s h4URN TO 2ELEASEv MUSHROOM BUTTON FOR
emergency stop
s 0ILOT LIGHT
*"ÓÊ- , -ÊUÊ* -/" Ê , *
Catalogue
Description
Number
Cable Sleeve with “Turn to Release”
Mushroom E-Stop Button
3 Button - 1 NO - All Single Speed
P03.1
3 Button - 2 NO - All Single Speed
P03.2
3 Button - 2 NO - All Two Speed
P03.D2
P03 Series stations have standard pendant station type legend
plates. Additional legend plates are available. Please call factory.
*"ÎÊ- , -ÊUÊ* -/" Ê , *
with E-Stop
0/ 3ERIES s 0ISTOL 'RIP
0/ 3ERIES s 0ISTOL 'RIP
0, 3ERIES s %RGONOMIC
Catalogue
Description
Number
Cable Sleeve with “Turn to Release”
Mushroom E-Stop Button
5 Button - All Single Speed
PL05
5 Button - 2 Two Speed, 2 Single Speed
PL05D2
7 Button - All Single Speed
PL07
7 Button - 2 Two Speed, 4 Single Speed
PL07D4
8 Button - All Single Speed (E-Stop, 6 op’s + Horn)
PL08
10 Button - All Single Speed (E-Stop, 8 op’s + Horn)
PL10
* Ê- , -ÊUÊ* -/" Ê , *
with E-Stop
SPECIFICATIONS
s %LECTRICAL RATINGS
P02 Series = 10 AMP: A600/Q600, A300/Q300
0 0, 3ERIES !-0
s /PERATING TEMPERATURE
-20°F to +170°F
s 3HOCK RESISTANCE
110G
s -ECHANICAL LIFE
1 million operations
Catalogue
Option
Number
Contact Blocks
PL00400
Pushbuttons
PL00500
Mushroom Head P/B
PL01300
