196
Electrical
Direct OEM Replacement Parts
Part #
Features & Applications
Specifications
Cross Reference
24-ICM270
• Dual function fan delay timer.
• Controls the circulating fan in heat pump, A/C
and forced air systems.
• OFF delay purges ducts of residual air.
• ON delay allows air to reach the proper comfort
level prior to energizing the fan.
• Control: 18-30 VAC
• Contact ratings: heat/ cool
speed.
N.O. 20 amps @ 240 VAC.
N.C. 10 amps @ 240 VAC.
• Time delays: blower off
time adjustable 90, 120,
150, 180 sec.
Robertshaw
• 695-003
Evcon
• 2702-300
Rheem
• 47-22827-01
• 47-22827-81
• 47-22827-82
• 47-22828-01
• 47-22828-02
Honeywell
• ST9120A1006
• ST9120A12004
24-ICM271
• Reliable solid state fan blower control.
• Specifically designed to replace popular gas
furnace centres.
• Pin selectable blower delays.
• High power, relay output.
• Dual function fan delay timer.
• Controls the circulating fan in heat pump, A/C
and forced air systems.
• OFF delay purges ducts of residual air.
• ON delay allows air to reach the proper comfort
level prior to energizing the fan.
• Control: 18-30 VAC.
• Contact ratings:
N.O. 20 amps.
N.C. 10 amps.
• Fixed time delays.
Robershaw
• 695-100
24-ICM272
• Cooling control module with fan delay.
• Integral low voltage terminal board with field
thermostat wiring.
• Electronic air cleaner output.
• High power, relay output.
• DC output for fan relays and 1st stage of elec-
tronic heater control.
• Interlock circuitry; prevents 2nd and 3rd stage
electric heat energization without proper fan
operation.
• Control: 18-30 VAC
• Contact ratings:
N.O. 20 amps
N.C. 10 amps
• Time delays: factory fixed
at 60 sec.
Texas Instruments
• 2FD-1
24-ICM273
• Solid state output.
• Silent operation "no clicking"
• Controls the circulating fan in heat pump, A/C
and forced air systems.
• OFF delay purges ducts of residual air.
• Control: 18-30 VAC.
Output
• Contact rating: 2 amps @
240 VAC.
• Time delays: factory fixed
at 60 sec.
EMI
• 240000-969
24-ICM275
• Microprocessor-based fan blower control.
• Built-in humidity relay.
• Manually adjustable post-purge OFF delay from
60-240 seconds.
• Electronic air cleaner output.
• Control: 18-30 VAC.
Output
• Contact ratings:
20 amps @ 240 VAC on
high.
10 amps @ 240 VAC on
low.
Robertshaw
• 695-101
Carrier
• CES110019
• HH84AA001
• HH84AA003
• HH84AA005
• HH84AA009
• HH84AA014
• HH84AA015
• HH84AA021
Fan Blower Control
Solid State Components
