198
Electrical
With LCD Diagnostics - Designed for 3-Phase Systems
Part #
Features & Applications
Specifications Cross Reference
24-ICM336
208/ 240 VAC
24-ICM337
460 VAC
• Specifically designed for 3-phase systems.
• Easy LCD programming and diagnostics.
• Helps prevent evaporator freeze-ups, low pressure cutouts
& liquid slugged compressors in low ambient conditions.
• Controls head pressure by varying the amount of airflow
through the condenser.
• Low temp cut-off & high temp set points.
• Temperature, pressure, milliamps, or DC voltage input.
• True sine wave output.
• Modulates voltage and frequency.
24-ICM336
• Control: 208-
240 VAC 1 to
3 HP.
24-ICM337
• Control: 480
VAC 1 to 5 HP.
• Motormaster III
• Hoffmann
Sensor Probes
Part #
Features & Applications
24-ICM375
24-ICM376
24-ICM377
• Probes for use with 24-ICM325, 24-ICM326, and 24-ICM327 head
pressure controls.
• Sensor probes, choose from (3) temperature ranges.
• 24-ICM375: 50° to 80°F (10° to 27°C).
• 24-ICM376: 70° to 100°F (21° to 38°C).
• 24-ICM377: 95 to 120°F (35° to 49°C).
24-ICM379
• Probe for use with 24-ICM325H, 24-ICM326H, and 24-ICM327H
head pressure controls with optional heat pump bypass features.
24-ICM380
• Optional pressure transducer for 24-ICM336 & 24-ICM337 three-
phase head pressure controls.
Outdoor Enclosure
Part #
Features & Applications
24-ACCOEO1
• It’s worth protecting the controls that protect your equipment!
• Rugged Steel Construction.
• Easy to mount.
• Protects controls from harsh environmental conditions such as
temperature, shock, humidity and vibration.
3-Phase Head Pressure Controls
Head Pressure Control Accessories
Solid State Components
