199
Electrical
Reliable Long Life Switching
Part #
Features & Applications
Specifications
Cross Reference
24-ICM600
• True dual stage control.
• Built-in thermostat.
- Adjustable set point: 55° to 90°F
- Adjustable Deadband: 2° to 20°F
- Adjustable Sequencer: 1 to 28 day
• Regulates 1 or 2 heating/ cooling systems.
• Compact housing.
• Safety system halon contacts.
• Memory on power loss.
• Accelerated test mode.
• Isolated inputs.
• Isolated solid state outputs.
• Built-in anti short-cycle delays.
• Status LED’s.
• Advance state switch.
• Ideal for refrigeration applications, commu-
nication substations, water plants anywhere
redundant systems are used.
• Control: 18-30 VAC.
• 2 amps max.
• Frequency: 50/ 60 Hz.
• Power consumption: 2
watts max/ lockout.
• Adjustable thermostat
features:
- Set point: 55° to 90°F.
- Deadband: 2° to 20°F.
- Sequencer: 1 to 28 day.
N/A
24-ICM601
• Low cost, open board version of the 24-ICM600.
• True dual stage control.
• Built-in thermostat.
- Adjustable set point: 55° to 90°F
- Adjustable Deadband: 2° to 20°F
- Adjustable Sequencer: 1 to 28 day
• Regulates 1 or 2 heating/ cooling systems.
• Safety system halon contacts.
• Memory on power loss.
• Accelerated test mode.
• Isolated inputs.
• Isolated solid state outputs.
• Built-in anti short-cycle delays.
• Status LED’s.
• Advance state switch.
• Ideal for refrigeration applications, commu-
nication substations, water plants anywhere
redundant systems are used.
• Control: 18-30 VAC.
• 2 amps max.
• Frequency: 50/ 60 Hz.
• Power consumption: 2
watts max/ lockout.
• Adjustable thermostat
features:
- Set point: 55° to 90°F.
- Deadband: 2° to 20°F.
- Sequencer: 1 to 28 day.
N/A
24-ICM602
• Low cost, open board lead lag control.
• Regulates one or two devices.
• Reliable, long life switching.
• Status LED’s.
• Ideal for refrigeration applications.
• Control: 18-30 VAC
(24 VAC).
• 2 amps max.
• Frequency: 50/ 60 Hz.
• Power consumption: 2
watts max/ lockout.
N/A
Lead-Lag Controls
Solid State Components
