Service Tools
Manifold
R410A Manifolds
Part #
46-MBC 46-MBD
46-MBH
46-MBB
Manifold
& (3) - 90cm (3') Hoses
Manifold
& (3) - 150cm (5')
Hoses
Part #
46-MBCS3 46-MBDP3
46-MBHP5
46-MBBP5
Manifold
& (3) - 150cm (5') Hoses
Manifold
& (3) 150cm (5')
Hoses (Ball Valve On End)
Part #
46-MBCS5 46-MBDP5
46-MBHP5E 46-MBBP5E
Refrigerant
R12, R22, R502. R134a, R404A, R507. R410A, R22, R404A R410A.
Pressure
(Units) PSI (°F)
PSI (°F)
PSI (°F)
PSI/ kPA (°C & °F)
Gauge Size
68mm (2.5")
68mm (2.5")
68mm (2.5")
68mm (2.5")
High Gauge #
46-RGCH 46-RGDH
46-RGHH
46-RGBH
Low Gauge #
46-RGCL
46-RGDL
46-RGHL
46-RGBL
Manifold
Part #
46-M6C
46-M6D
Manifold
& (3) - 90cm (3') Hoses
Part #
46-M6CS3
46-M6DP3
Manifold
& (3) - 150cm (5') Hoses
Part #
46-M6CS5
46-M6DP5
Refrigerant
R12, R22, R502.
R134a, R404A, R507.
Pressure (Units)
PSI (°F)
PSI (°F)
Gauge Size
68mm (2.5")
68mm (2.5")
High Gauge Part #
46-RGCH
46-RGDH
Low Gauge Part #
46-RGCL
46-RGDL
Two Valve Piston Manifolds - Aluminum
Two-Valve Piston Aluminum Manifolds - 1⁄4" SAE Fittings
Two Valve BlackMax™ Manifolds
• High gloss anodized aluminum block.
• Exclusive Triple Seal™ valve system.
• Valve stems retract fully for maximum flow.
• Back seating o-ring seals valve nut when fully open.
• No-flutter gauge design with rugged metal housing.
• Additional Schrader valve "T" port.
• Extra large knobs for easy grip.
2-Valve Piston Brass Manifolds - 1⁄4" SAE Fittings
PRO-SET Two Valve Manifolds
• Quality forged brass body.
• Sliding double o-ring piston valve system.
• Full sized porting for maximum flow.
• No-flutter gauge design with rugged metal housing.
• Large easy to grip knobs.
Two Valve Piston Manifolds - Brass
46-MBC
Illustrated
46-M6C
Illustrated
BlackMax™
Manifolds
