Service Tools
31⁄2" Liquid Filled Gauges
High Gauge
Part #
Low Gauge
Part #
Refrigerant
Pressure (Units)
46-RGMH 46-RGML
R12, R22, R502.
PSI (°F)
46-RGRH 46-RGRL
R410A.
PSI/ kPA (°C & °F)
46-RGPH 46-RGPL
R22, R134a, R404A.
PSI/ kPA (°C & °F)
Manifold Replacement Parts
BlackMax™ Piston Manifolds
Part #
Description
46-MXPV
Piston repair kit.
46-MXPVO
Piston valve seals repair kit (services 2 valves).
46-MXMH
Hook assembly.
46-MXPK
1 Valve handle with screw.
46-386
(T) 1⁄4" SAE fitting.
46-388
(T) 1⁄2" Acme fitting.
Manifold Replacement Parts
PRO-SET® Diaphragm Manifolds
Part #
Description
46-MXC
Manifold plastic carrying case
46-MXK
1 valve handle & 4 labels (HI, LOW, VAC, REF)
46-MXMH
Hook assembly
46-MXP
Replacement o-ring/ piston for brass manifold
46-M2XRK
Diaphragm valve repair kit (2 valves)
46-M4XRK
Diaphragm valve repair kit (4 valves)
46-M2XHA
2-way hose anchor assembly
46-M4XHA
4-way hose anchor assembly
46-386
(T) 1⁄4" SAE fitting.
46-388
(T) 1⁄2" Acme fitting.
46-147
(straight)1⁄4" SAE fitting.
46-109
(straight) 1⁄2" Acme fitting.
Replacement Manifold Gauges
PRO-SET® 68mm (21⁄2") Gauges With Metal Casting
• No-flutter gauge design.
• Easy to read colour coded dials.
• Durable metal casing.
• Front calibration access port.
• High impact pop-in lexan lens (46-RGX68L).
• 1/8" NPT brass connection
21⁄2" Gauges
High Gauge
Part #
Low Gauge
Part #
Refrigerant
Pressure (Units)
46-RGBH 46-RGBL
R410A.
PSI/ kPA (°C & °F)
46-RGCH 46-RGCL
R12, R22, R502.
PSI (°F)
46-RGDH 46-RGDL
R134a, R404A, R507.
PSI (°F)
46-RGHH 46-RGHL
R22, R410A, R404A.
PSI (°F)
46-RGIH 46-RGIL
R134a
PSI/ kg/ cm² (°C & °F)
46-RGTH 46-RGTL
R22, R134a, R404A.
PSI/ kPA (°C)
46-RGYH 46-RGYL
R407C, R22.
PSI/ kPA (°C)
46-RGZH 46-RGZL
R12, R22, R502.
PSI/ kg/ cm² (°C & °F)
PRO-SET® 80mm (31⁄2") Gauges Liquid Filled
• Glycerine-filled for maximum accuracy.
• Extra large easy to read scales.
• No-flutter gauge design.
• Rear calibration access port.
• 1/8" NPT brass connection
46-RGRL
&
46-RGRH
Illustrated
Manifold Replacement Parts
46-386 46-MXPV 46-147 46-151
46-MXMH
46-MXPVO
46-MXPK 46-MXK
46-RGTH
&
46-RGTL
Illustrated
46-RGCL
Illustrated
