257
Service Tools
Standard Hoses
Length
Yellow
Blue
Red
3-Pack
90cm (3')
46-HS3Y 46-HS3B 46-HS3R 46-HS3
120cm (4')
46-HS4Y 46-HS4B 46-HS4R 46-HS4
150cm (5')
46-HS5Y 46-HS5B 46-HS5R 46-HS5
180cm (6')
46-HS6Y 46-HS6B 46-HS6R 46-HS6
240cm (8')
46-HS8Y 46-HS8B 46-HS8R 46-HS8
300cm (10')
46-HS10Y 46-HS10B 46-HS10R 46-HS10
46-HXG Replacement Gaskets • 46-HXD Replacement Depressor
Standard Hoses With 45° Ball Valve On One End
Unique 45° ball valve at end.
Length
Yellow
Blue
Red
3-Pack
90cm (3')
46-HS3YE 46-HS3BE 46-HS3RE 46-HS3E
150cm (5')
46-HS5YE 46-HS5BE 46-HS5RE 46-HS5E
180cm (6')
46-HS6YE 46-HS6BE 46-HS6RE 46-HS6E
240cm (8')
46-HS8YE 46-HS8BE 46-HS8RE 46-HS8E
46-HXG Replacement Gaskets • 46-HXD Replacement Depressor
Standard Hoses With Micro Seal™ Valve On One End
Micro Seal™ fittings automatically seal & prevent refrigerant loss
when disconnected.
Length
Yellow
Blue
Red
3-Pack
90cm (3')
46-HS3YA 46-HS3BA 46-HS3RA 46-HS3A
150cm (5')
46-HS5YA 46-HS5BA 46-HS5RA 46-HS5A
180cm (6')
46-HS6YA 46-HS6BA 46-HS6RA 46-HS6A
240cm (8')
46-HS8YA 46-HS8BA 46-HS8RA 46-HS8A
46-HXGA Replacement Gaskets
Standard In-Line Ball Valve Hoses
Ball valve crimped directly in-line to reduce refrigerant loss.
Length
Yellow
Blue
Red
3-Pack
90cm (3')
46-HS3YL 46-HS3BL 46-HS3RL 46-HS3L
150cm (5')
46-HS5YL 46-HS5BL 46-HS5RL 46-HS5L
180cm (6')
46-HS6YL 46-HS6BL 46-HS6RL 46-HS6L
240cm (8')
46-HS8YL 46-HS8BL 46-HS8RL 46-HS8L
46-HXG Replacement Gaskets • 46-HXD Replacement Depressor
Charging Hoses - Standard
PRO-SET® Standard Charging Hoses
• All-weather flexibility and strength.
• 750 psi working pressure (3000 psi burst).
• Blow-off grooves channel refrigerant to prevent spray back.
• Fully adjustable valve core depressors.
• Available with Micro Seal™ or ball valve fittings.
• Extra deep knurling on nuts for easy grip.
• 1⁄4" SAE fittings with 45° bend on one end.
• Leak-proof eight-sided crimp.
46-HS3
Standard Hoses
46-HS3YE
Illustrated
46-HS3BA
Illustrated
46-HS3RL
Illustrated
Charging Hoses
