18
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Part #
HP Spd/RPM Amps Volts
Rot
Shaft
Body Type Mntg
Cross
FM-RFM230
1/12
1/3200 0.60 230
REV.PLUG
2.5"x1/4" 7.00
PSC/INC Stud
024-24115-020, 714
FM-RFM9
1/12
1/3000 1.10 208/230
CCW
2.8"x5/16" 6.30
SP
Stud
Keeprite 501493,
FM-RFM232
1/10
1/3450 0.55 208/230
CW
2.9"x5/16" 5.00
PSC/INC Stud
ICP 1171348, JF1H092N
Carrier HC30GB232
FM-RFM410
1/10
1/3000 1.50 115/230
REV.
3.7"x1/4" 7.10
PSC/INC Lugs Fasco D410, D412, Reznor
FM-RFM187
1/10
1/3400 0.30 460
CW
8.8"x3/8" 6.80
PSC/INC Stud
York 024-2500-5005, 024-
2500-5702, D1187
FM-RFM460
1/10
1/3200 0.30 460
REV.
2.5"x1/4" 7.00
PSC/INC Stud
YVFM450, Fasco D1171 York
024-24115-700
FM-RFM78
1/9
1/3200 1.30 115/230
REV.
3.3"x5/16" 4.10
PSC/INC Stud
RFM7&8, Reznor 43846-115V,
43424-208/230V
* Note: Without Centrifugal Switch
Fig. 1
FM-RFM230
Fig. 4
FM-RFM410
Fig. 5
FM-RFM187
Fig. 6
FM-RFM460
Fig. 7
FM-RFM78
Fig. 2
FM-RFM9
Fig. 3
FM-RFM232
Cooling Fan Kits
Part # Rotation
Kits Description
92-FMK
CW
• 1 3/4" Diameter.
• 5/16" Hub I.D. with 1/4" adapter.
• (4) Spacers, (4) 10/32 & (4) 8/32 nuts.
92-FMK1
CCW
92-FMK1
Illustrated
Flue Exhaust Motors
