33
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Fig. 2
Fig. 3
*Notes:
1 - Comes with gasket
2 - Comes with three (3) brackets, fastening hardware, drain tubing & instructions.
3 - Includes pressure switch, two (2) gaskets, mounting plate, silicone tubing & instructions
Nordyne, Frigidaire, Miller
Part #
HP Volts Amps Type RPM Rot. Body Frame Bearing Cap Shaft
Cross
Fig
FB-RFB303
1/50
115 0.77 SP 1/3000 CW 7.6" 3.3" Ball
-
-
NEW!
512A, 303875
1
FB-RFB903
-1
1/45
115 1.10 SP 1/3000 CCW 5.6" 3.3" Sleeve -
-
G5RA, G6RA, G3 Mid Eff.
Res.: 903111, UE9454
2
FB-RFB902
1/19
115 0.70 PSC 1/3450 CCW 5.5" 3.3" Sleeve 4/370 -
G5RC, G6RC, G1, G4 High
Eff Res.: 902977
3
OEM Replacement Motors
Part # HP Volts Amps Type RPM Rot. Body Frame Bearing Cap Shaft
Cross
Fig
FB-RFB181
-2
1/54
115 1.2 SP 1/3200 CW 6.6" 3.3" Ball
-
-
Airco High Eff HCS-2
60, 75, 81, 90 Left Hand
Discharge Res: 18102
4
FB-RFB200
-2
1/54
115 1.2 SP 1/3200 CCW 6.6" 3.3" Ball
-
-
HCS-2 High Eff. 60, 75, 81,
90 Right Hand Discharge
Residential: 20082, 11051403
5
FB-RFB140
1/49
115 1.4 SP 1/3400 CCW 5.6" 3.3" Sleeve -
-
Consolidated NUP
54-3, 72-3 High Eff. Res:
4246100, JAIN107NS
6
FB-RFB112
-3
1/45
115 1.30 SP 1/3000 CCW 6.0" 3.3" Sleeve -
-
Airco HMS/HMS-2T Mid Eff.
Res: 26986, 26987, 28436
7
FB-RFB467
1/30
115 1.70 SP 3000 CW 5.94 Skel
Ball
-
-
29467
8
FB-RFB111
1/25
120 1.2 SP 1/3000 CCW 6.0" 3.3" Sleeve -
-
Residential: SBC375,
CPL1132
9
FB-RFB297
1/20
115 0.75 PSC 1/3450 CW 6.6" 3.3" Sleeve 4/370 -
NEW!
29836, 29793, 7062-
5511, 7062-6349
10
FB-RFB203
1/20
208/230 0.9 SP 1/3000 CCW 8.5" 3.3" Ball
-
-
Com. Rooftop 3255A
11
FB-RFB130
1/18
115 0.70 PSC 1/3450 CCW 5.0" 3.3" Sleeve 4/370 -
Consolidated NUP N12, 16,
20, 90-3, 108-5, 126-5 H.E.
Res: 4246101
12
Olsen
Fig. 4
Fig. 8
Fig. 9
Fig. 10
Fig. 11
Fig. 12
Fig. 5
Fig. 6
Fig. 7
Fig. 1
