31
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Lennox
(cont. next page...)
Part # HP Volts Amps Type RPM Rot. Body Frame Bearing Cap Shaft
Cross
Fig
FB-RFB135
1/65
115 0.7 SP 1/3000 CW 5.5" 3.3" Sleeve -
-
Air-Flo Unit Heater Com.:
Lennox 19J04, Fasco
7121-8812, 7021-8657
1
FB-RFB390
1/65
115 0.7 SP 1/3000 CCW 5.5" 3.3" Sleeve -
-
Res: 88J3901, 7021-9262, A219
2
FB-RFB401
1/60
115 1.3 SP 1/2800 CW 5.96" Skel
Ball
-
-
NEW!
66401, 7021-1108,
7021-9242, 7021-9311, 7021-
9455, 7021-9640, 7021-9657,
J238-8171, 85L4901, 88K8401,
67M5401, 10K5101, 10K5301,
10K5301P, 27K5201, 27K5201P
3
FB-RFB495
1/50
115 1.4 SP 1/3000 CW 5.3" Skel
Ball
-
-
24W95, 31L5501
4
FB-RFB43
1/50
115 0.8 SP 1/3000 CW 5.8" 3.3" Sleeve -
-
G24 Mid Eff. 43K4101,
101202-02
1
FB-RFB98
-1
1/50
115 0.8 SP 1/3000 CW 5.8" 3.3" Sleeve -
-
G24 Mid Eff. 11K98 Kit
1
FB-RFB99
-1
1/50
115 0.8 SP 1/3000 CW 5.8" 3.3" Sleeve -
-
G24 Mid Eff. 11K99 Kit
1
FB-RFB164
-2
1/50
115 0.8 SP 1/3000 CW 5.8" 3.3" Sleeve -
-
Res: 46K4101,
Fasco 7021-9593
1
FB-RFB840
1/50
115 1.3 SP 1/3000 CW 5.83" Skel
Ball
-
-
88K8401, 85L4901
5
FM-RFM1198
1/30
115 1.5 SP 1/3200 CCW 3.40" 3.3" Sleeve -
2¼"×5/16"
Roof Top Com: Lennox
25J1201, Fasco 7121-8774
6
FB-RFB790
1/28
115 1.8 SP 1/3000 CCW Skel
Ball
-
-
Res: 60M7901, 7058-0217,
A207
7
FB-RFB810
1/28
115 1.8 SP 1/3000 CCW Skel
Ball
-
-
Com: 60M8101, 7058-0322,
A208
8
FM-RFM890
1/25
208/230 0.7 SP 1/3200 CCW 3.29" 3.3" Ball
-
2.3"×5/16"
GCS3 Roof Top Com: Lennox
98G8901 Fasco 7121-7091
BLW. WHL - 66-A8677
9
FB-RFB385
1/20
115 0.8 PSC
2/3200
/2800
CCW 3.3" Ball
7.5/370 -
Res: 38M5001, 7062-5441,
A209
10
Fig. 1
Fig. 4
Fig. 2
Fig. 3
*Notes:
1 - Comes with gaskets, pressure switch & mounting hardware
2 - Features air tube fitting
Fig. 5
OEM Replacement Motors
Fig. 9
Fig. 10
Fig. 8
Fig. 6
Fig. 7
