28
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Heil Quaker
Part #
HP Volts Amps Type RPM Rot. Body Frame Bearing Cap Shaft
Cross
Fig
FB-RFB672
1/100
115 0.60 SP 1/3150 CCW 5.71" 3.3" Sleeve -
-
A064, 610672, X89-455
6
Coupling
Included
G.S.W.
Part # HP Volts Amps Type RPM Rot. Body Frame Bearing Cap Shaft
Cross
Fig
FB-RFB127
-2
1/20
115 1.3 SP 1/3200 CCW 12.5" 3.3" Sleeve -
-
John Woods Water Heater
GSW 63217, Fasco
7021-8347
4
FB-RFB172
1/20
115 1.3 SP 1/3200 CCW 12.5" 3.3" Sleeve -
-
John Woods Water Heater
GSW 63217, Fasco
7021-9756
5
Fig. 5
Fig. 4
*Notes:
1 - Feature an internal fan, stainless steel shaft and built-in centrifugal switch
2 - Includes Coupling & hose clamps
Fig. 6
OEM Replacement Motors
General Replacement
Part # HP Volts Amps Type RPM Rot. Body Frame Bearing Cap Shaft
Cross
Fig
FM-RFM2
-1
1/35
115/230 1.3/.65 SP 1/3000 CCW 5.8" 3.3" Ball
-
3.9"×5/16"
Franklin 80137, Fasco
D406, D408
1
FM-RFM10
-1
1/35
115/230 1.2/0.6 SP 1/3000 CW 5.6" 3.3" Ball
-
3.9"×5/16"
EJ Walsh 8211910172,
Fedders
1
FM-RFM410
1/10
115/230 1.5/0.7 PSC 1/3000 Rev. 7.1" 3.3" Ball 7.5/370 3.7"×1/4"
Fasco D410, D409, D412,
Reznor
2
UE-374
1/8
115 1.8 PSC 1/3000 Rev. 6.5" 3.3" Ball
4/370 3.75"×1/4"
Magnetek 371
3
UE-371
1/8
208/230 0.89 PSC 1/3000 Rev. 6.5" 3.3" Ball
4/370 3.75"×1/4"
Magnetek 374
3
Fig. 1
Fig. 2
Fig. 3
