Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Lennox
(cont. from previous page...)
Fig. 3
Fig. 4
Fig. 5
Fig. 6
Fig. 1
Fig. 2
*Notes:
1 - Comes with gasket set
2 - Comes with gasket. Built-in centrifugal switch
3 - Features a built-in variable speed control
Part # HP Volts Amps Type RPM Rot. Body Frame Bearing Cap Shaft
Cross
Fig
FB-RFB547
-1
1/20
115 1.8 SP 1/3400 CW 5.8" 3.3" Ball
-
-
G26 High Eff. Series Res:
68K21, Fasco 7021-9450
1
FB-RFB550
1/16
230 0.83 SP 1/3000 CCW 5.91" 3.3" Ball
-
-
Com: 25M5501,
7021-11231, A217
2
FB-RFB811
1/15
115 2.4 SP 1/3400 CCW 6.1" 3.3" Ball
-
-
Res: 81M1601,
7021-11634, A211
3
FB-RFB101
-2
1/12
208/230 0.5 PSC 1/3200 CCW 8.25" 3.3" Ball
3/370
-
GCS Roof Top Com: Lennox
23G8101, 135327, 074,
28G6601, Fasco
7062-1794, 7062-3577
4
FB-RFB701
1/10
208/230 0.6 PSC 1/3200 CCW 6.75" 3.3" Ball
4/370
-
Roof Top Com: Lennox
98G8701
5
FB-RFB320
1/10
460 .38/.33 PSC 1/3200 CW 6.8" 3.3" Sleeve 4/370
-
Com: 69M3201, 7062-5554,
7062-4051, 7062-4518,
97J8101
6
OEM Replacement Motors
Modine
Newmac
Part #
HP Volts Amps Type RPM Rot. Body Frame Bearing Cap Shaft
Cross
Fig
FB-RFB599
1/15
115 2.4 SP 1/3430 CW 9.03 3.3" Sleeve -
-
NEW!
5H073598-001,
7021-9045, 7021-12659
7
FB-RFB598
1/15
200/230 .95/1.1 SP 1/3430 CW 9.03 3.3" Sleeve -
-
5H73598-2
7
Part #
HP Volts Amps Type RPM Rot. Body Frame Bearing Cap Shaft
Comments
Fig
R7-RB33
-3
1/55
115 0.88 SP 1/3200 CW 6.6" 3.3" Sleeve -
-
Oil & Wood Furnace
2040001
8
Fig. 7
Fig. 8
