Sump Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
24
A
Professional Plumbing
Series BP-HT
High Temperature - 3/4" Spherical Solids Handling
Manual & Automatic - Submersible
inches
(mm)
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
BP314HT
096737 1/3
115/1 60 1750
A
8.0
19.0
14/3 SOOW 0.560 (14.2)
BP314HTA
096738 1/3
115/1 60 1750
A
8.0
19.0
14/3 SOOW 0.560 (14.2)
BP314HTAU
096739 1/3
115/1 60 1750
A
8.0
19.0
14/3 SOOW 0.560 (14.2)
BP314HTBR
096742 1/3
115/1 60 1750
A
8.0
19.0
14/3 SOOW 0.560 (14.2)
BP314HTABR 096743 1/3
115/1 60 1750
A
8.0
19.0
14/3 SOOW 0.560 (14.2)
BP314HTAUBR 096744 1/3
115/1 60 1750
A
8.0
19.0
14/3 SOOW 0.560 (14.2)
BP324HT
096740 1/3
230/1 60 1750
A
4.0
13.0
14/3 SOOW 0.560 (14.2)
BP324HTAU
096741 1/3
230/1 60 1750
A
4.0
13.0
14/3 SOOW 0.560 (14.2)
BP324HTBR
096745 1/3
230/1 60 1750
A
4.0
13.0
14/3 SOOW 0.560 (14.2)
BP324HTAUBR 096746 1/3
230/1 60 1750
A
4.0
13.0
14/3 SOOW 0.560 (14.2)
Mechanical Switch on BP314HTA, cord 14/2, SJOOW, 0.370 (9.4MM) O.D., Piggy-Back Plug.
Mechanical Switch on BP314HTAU & BP324HTAU, cord 14/2, SJOOW, 0.370 (9.4MM) O.D.
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
3.) MUST USE A
HIGH TEMPERATURE
WIDE ANGLE LEVEL CONTROL IN HIGH TEMPERATURE APPLICATIONS.
1/13
BP314HT, BP314HTBR
BP324HT, BP324HTBR
BP314HTA. BP314HTABR
BP314HTAU, BP314HTAUBR
BP324HTAU, BP324HTAUBR
