USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
Sump Pumps
23
A
Professional Plumbing
Series BP-HT
High Temperature - 3/4" Spherical Solids Handling
Manual & Automatic - Submersible
DISCHARGE ...................................
2” NPT, Female, Vertical
LIQUID TEMPERATURE ................
200°F (93°C) Continuous
VOLUTE.............................................
(BP) Cast Iron, (BP-BR) Bronze
MOTOR HOUSING ...........................
(BP) Cast Iron, (BP-BR) Bronze
SEAL PLATE .....................................
(BP) Cast Iron, (BP-BR) Bronze
IMPELLER:
Design
......................
2 Vane open, Dynamically Balanced, ISO G6.3
Material
.....................
Bronze 81-3-7-9
SHAFT
..............................................
416 Stainless Steel
SQUARE RINGS................................
Buna-N
HARDWARE ......................................
300 Series Stainless Steel
PAINT .................................................
Air Dry Enamel
SEAL:
Design
.......................
Single Mechanical, Oil-Filled Reservoir,
Secondary Exclusion Seal
Material
......................
Carbon/Ceramic/Buna-N
CORD ENTRY....................................
15 ft. (5m) Quick Disconnect Cord with plug
On 115 volt, Pressure Gromment for sealing
and strain relief
UPPER BEARING..............................
Single Row, Ball, Oil Lubricated
LOWER BEARING.............................
Single Row, Ball, Oil Lubricated
MOTOR, SINGLE PHASE .................
Permanent Split Capacitor (PSC). Oil Filled.
Includes Overload Protection in Motor
Insula
tion
...................
Class B
LEVEL CONTROLS........................... "A" -
High Temperature, Wide Angle,
Mechanical, N/O, 15 ft (5m) cord with
Piggy-Back Plug,
"AU" -
High Temperature, Wide Angle,
Polypropylene, Mechanical, N/O Integral to
pump. ON and OFF points are adjustable
OPTIONAL EQUIPMENT ....................
Seal Material, Additional Cable
Series: BP314HT & BP324HT
1/3HP, 1750RPM, 60Hz,
Cast Iron & Bronze
DESCRIPTION:
GENERAL PURPOSE PUMP FOR RESIDENTIAL AND
LIGHT INDUSTRIAL SUMP APPLICATIONS
Testing is performed with
water specific gravity of 1.0
@ 68˚F (20˚C), other fluids
may vary performance
4/04
