66
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Blowers
Blowers
Blowers
40mm × 40mm × 20mm
(1.57" × 1.57" × 0.79")
• Mounting Centres 32mm (1.26")
Part #
Volts CFM Bearing Impeller
Noise Connection Weight
RF265
12VDC 7 Sleeve Plastic
26dB (A)
Wire Leads
40g
RF268
12VDC 8.5 Sleeve Plastic
31dB (A)
Wire Leads
40g
60mm × 60mm × 25mm
(2.36" × 2.36" × 1.00")
• Mounting Centres 50mm (1.97")
Part #
Volts CFM Bearing Impeller
Noise Connection Weight
RF270
12VDC 16.7 Sleeve Plastic
25dB(A)
Wire Leads
75g
80mm × 80mm × 25mm
(3.15" × 3.15" × 1.00")
• Mounting Centres 71.5mm (2.82")
Part #
Volts CFM Bearing Impeller
Noise Connection Weight
RF275
12VDC 30 Sleeve Plastic
24dB(A)
Wire Leads
85g
RF280
12VDC 37 Sleeve Plastic
30dB(A)
Wire Leads
85g
92mm × 92mm × 25mm
(3.62" × 3.62" × 1.00")
• Mounting Centres 82mm (3.25")
Part #
Volts CFM Bearing Impeller
Noise Connection Weight
RF285
12VDC 50.5 Sleeve Plastic
30dB(A)
Wire Leads
120g
RF287
12VDC 41.5 Sleeve Plastic
28dB(A)
Wire Leads
120g
120mm × 120mm × 25mm
(4.70" × 4.70" × 1.00")
• Mounting Centres 104.8mm (4.13")
Part #
Volts CFM Bearing Impeller
Noise Connection Weight
RF290
12VDC 74.5 Sleeve Plastic
44dB(A)
Wire Leads
150g
RF292
12VDC 61.4 Sleeve Plastic
38dB(A)
Wire Leads
150g
DC Axial Fans
Rotom Room-to-Room Air Booster
The RDF150 is a simple, inexpensive, easy to install and
remarkably silent solution to uncomfortable and frustrating
room to room heating or cooling problems. Mounted in a
doorway and featuring a rotating bracket, it is possible to
position or direct the enhanced airflow from one remote area
to another for maximum, even heat distribution.
RDF150
Kit includes: · Point of Purchase box with sleeve
· 12' Cord with inline switch
· Metal impeller
· Die-cast aluminium housing
· Chrome fan guards
· Mounting swivel bracket & hardware
