Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
By-Pass Vacuum Motors
Vacuum Motors
Part #
Volts Amps Bearings Discharge
Comments
116148-00
115
6.3 Ball/Sleeve Thru-Flow
Standard Design
Part #
Volts Amps Bearings Discharge
Comments
116378-00
115
7.5 Ball/Ball
Thru-Flow
Standard Design
4.8" Diameter Two Stage
4.3" Diameter Two Stage
4.8" & 5.7" Diameter - "Lamb - Ametek" Vacuum Motors
5.7" Diameter Single Stage
5.7" Diameter Two Stage
Part #
Volts Amps Bearings Discharge
Comments
116309-00
115
6.8 Ball /Sleeve Thru-Flow
Standard Design, Replaces 115717
116455-50
115
6.8 Ball /Sleeve Thru-Flow
Standard Design
116297-00
115
6.9 Ball /Sleeve Thru-Flow
High Efficiency Design, Replaces 115924
117760-00
115
7.0 Ball/Ball
Thru-Flow
Standard Design
119400-00
115
7.0 Ball/Ball
Thru-Flow
Standard Design
115955
220/240
3.2 Ball /Sleeve Thru-Flow
Standard Design
116310-00
220/240
3.8 Ball /Sleeve Thru-Flow
Standard Design
Part #
Volts Amps Bearings Discharge
Comments
115756
220
3.82 Ball/Sleeve Thru-Flow
Standard Design
115792
115
4.0 Ball/Sleeve Thru-Flow
Specially Wound for Reduced Performance
116670-50
230
4.6 Ball/Sleeve Thru-Flow
Standard Design
116311-00
115
7.7 Ball/Sleeve Thru-Flow
Standard Design, Replaces 115737
116311-01
115
7.7
Ball/Ball
Thru-Flow
Standard Design, Replaces 115750
115744
115
8.0 Ball/Sleeve Thru-Flow Automatic Thermal Overload, Standard Design
116457-00
115
8.3 Ball/Ball
Thru-Flow
Standard Design
116669-50
115
8.6 Ball/Ball
Thru-Flow
Standard Design
116227-00
115
8.8
Ball/Ball
Thru-Flow Two Speed, Replaces 115736, Standard Design
116671-50
115
9.4 Ball/Sleeve Thru-Flow
Standard Design
115982
115
9.5 Ball/Sleeve Thru-Flow
High Efficiency Design
116429-00
115
9.6 Ball/Sleeve Thru-Flow
High Efficiency Design, Automatic Thermal
Overload
115923
115
9.7
Ball/Ball
Thru-Flow
High Efficiency Design
116432-00
115
10.6
Ball/Ball
Thru-Flow
Standard Design
116312-00
220
4.0 Ball/Sleeve Thru-Flow
Standard Design, Replaces 115756
116343-00
230
4.7 Ball/Sleeve Thru-Flow
High Efficiency Design
Typical Applications :
Canister Type Vacuums, Utility Vacuums, Light Duty Commercial, Dry Applications Only
