67
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Blowers
Blowers
80mm × 80mm × 38mm
(3.15" × 3.15" × 1.5")
• Mounting Centres 71.5mm (2.82")
Part # Watts Volts CFM RPM Bearing Impeller Noise Connection Weight
RF200
10
115
32
3100 Sleeve Metal
34db (A) Wire Leads 420g
RF201
9
115
21 2000 Sleeve Metal
26db (A) Wire Leads 420g
RF202
10
230
32 3100 Ball
Metal
34db (A) Wire Leads 420g
120mm × 120mm × 38mm
(4.72" × 4.72" × 1.5")
• Mounting Centres 105mm (4.13")
Part # Watts Volts CFM RPM Bearing Impeller Noise Connection Weight
RF205
22
115 106 3000 Sleeve Metal
50db (A)
Terminal
600g
RF210
22
115 106 3000 Ball
Metal
50db (A)
Terminal
600g
RF225
22
115 106
3000 Ball
Metal
50db (A) Wire Leads 600g
RF215
21
230 106 3000 Sleeve Metal
50db (A)
Terminal
600g
RF220
21
230 106 3000 Ball
Metal
50db (A)
Terminal
600g
119mm × 119mm × 38mm
(4.69" × 4.69" × 1.5")
• Mounting Centres 105mm (4.13")
Part # Watts Volts CFM RPM Bearing Impeller Noise Connection Weight
RF230
12
115 106
3100 Sleeve Plastic 46db (A)
Terminal
530g
RF235
12
115 106
3100 Ball
Plastic 46db (A)
Terminal
530g
RF236
15
230 106 3100 Sleeve Plastic 46db (A)
Terminal
530g
RF237
15
230 106 3100 Ball
Plastic 46db (A)
Terminal
530g
150mm × 150mm × 55mm
(5.9" × 5.9" × 2.2")
• Mounting Centres 162mm (6.38")
Part # Watts Volts CFM RPM Bearing Impeller Noise Connection Weight
RF240
42
115 230
3400 Ball
Plastic 53db (A) Wire Leads 1kg
RF245
40
230 230
3400 Ball
Plastic 53db (A) Wire Leads 1kg
150mm × 172mm × 38mm
(5.9" × 6.7" × 1.5")
• Mounting Centres 162mm (6.38")
Part # Watts Volts CFM RPM Bearing Impeller Noise Connection Weight
RF247
28
115 212 3400 Ball
Plastic 58db (A)
Terminal
720g
RF248
26
230 212 3400 Ball
Plastic 58db (A)
Terminal
720g
180mm × 180mm × 90mm
(7.1" × 7.1" × 3.5")
• Mounting Centres 152.7mm (6.01")
Part # Watts Volts CFM RPM Bearing Impeller Noise Connection Weight
RF249
72
115 460 3400 Ball
Plastic 59db (A)
Screw 2.2kg
254mm × 254mm × 89mm
(10" × 10" × 3.5")
• Mounting Centres 247mm (9.72")
Part # Watts Volts CFM RPM Bearing Impeller Noise Connection Weight
RF250
35
115 547 1650 Ball
Plastic 55db (A)
Terminal
1.9kg
RF255
33
230 547 1650 Ball
Plastic 55db (A)
Terminal
1.9kg
Part #
Size
T8-CFG-60M
66mm
T8-CFG-80M
80mm
T8-CFG-92M
92mm
T8-CFG-120M
120mm
T8-CFG-150M
150mm
T8-CFG-254M
254mm
Axial AC Power Cords
BareWire
- 2 Pin molded connection to bare wire
leads.
Plug
- 2 Pin molded connection to 2 prong plug.
Bare Wire
Description
Plug
T8-CFC-T24
60.96cm (24") Cord
T8-CFC-T24P
T8-CFC-T48
121.92cm (48") Cord
T8-CFC-T48P
T8-CFC-T72
182.88cm (72") Cord
T8-CFC-T72P
T8-RF200
illustrated
Plastic Fan Guards
Mounting: Plastic Tabs
Part #
Size
T8-CFG-80P
80mm
T8-CFG-120P
120mm
T8-RF210
illustrated
T8-RF230
illustrated
T8-RF245
T8-RF250
T8-CFC-T24
Note: T8-CFG-80M, 120M, 150M
are also available in black.
*
Axial Fan Features:
• Die-cast Aluminum Housing
• Shaded Pole Motor
• Impedance Protection
• CSA & UL Approved.
• Operating Temp. Range
-10°C to 70°C
• Metal or Plastic Impellers
• Sleeve or Ball Bearings
Metal Fan Guards
AC Axial Fans
