61
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
By-Pass Vacuum Motors
Vacuum Motors
7.2" Two Stage
Part #
Volts Amps Bearings Discharge
Comments
117465-13
120
11.3 Ball/Ball Tangential
Redesign
117508-13
120
11.4 Ball/Ball
Peripheral
Redesign
117467-00
120
12.2 Ball/Ball Tangential
Redesign
115991
120
13 Ball/Ball Tangential
Old Style
115962
115
13.0 Ball/Ball
Peripheral Air Sealed Bearing Protection, Epoxy Coated Fan Case
117465-00
115
13.3 Ball/Ball Tangential
Standard Design, Replaces 115334, 116465-00
115330
115
13.5 Ball/Ball
Peripheral
Standard Design
115334
115
13.5 Ball/Ball Tangential
Standard Design
115937
115
13.5 Ball/Ball
Tangential
Air Sealed Bearing Protection, Epoxy Coated Fan Case,
Replaces 115837
117467-00
115
14.5 Ball/Ball Tangential
“High Performance” Design, Replaces 116467-00
117549-12
120
15.3
B/B Tangential
Premier Design
115963
220
5.5 Ball/Ball
Peripheral Air Sealed Bearing Protection, Epoxy Coated Fan Case
115684
220/240
5.5 Ball/Ball Tangential
Epoxy Coated Fan Case
115950
220/240
5.5 Ball/Ball Tangential Air Sealed Bearing Protection, Epoxy Coated Fan Case
115519
220/240
6.0 Ball/Ball
Peripheral
Epoxy Coated Fan Case
5.7" & 7.2" Diameter - "Lamb - Ametek" Vacuum Motors
Typical Applications :
Utility Vacuums, Commercial Vacuums, Carwash Vacuums, Steam Carpet Cleaners
Peripheral Discharge
Tangential Discharge
5.7" Three Stage
Part #
Volts Amps Bearings Discharge
Comments
116514-13
24VDC
21.0 Ball/Ball
Peripheral
Standard Design
116515-13
24VDC
21.0 Ball/Ball
Tangential
Standard Design
116598-13
24VDC
22.7 Ball/Ball
Peripheral
"Acoustek" Design
116512-13
36VDC
17.4 Ball/Ball
Peripheral
Standard Design
116513-13
36VDC
17.4 Ball/Ball
Tangential
Standard Design
119432-13
36VDC
17.4 Ball/Ball
Tangential
Standard Design
116565-00
115
10.3 Ball/Ball
Tangential
Standard Design
116565-13
115
10.3 Ball/Ball
Tangential
Standard Design
116566-13
115
10.3 Ball/Ball
Peripheral
Standard Design
116764-13
115
10.7 Ball/Ball
Peripheral
"Acoustek" Design
116765-00
115
10.7 Ball/Ball
Tangential
Standard Design
116765-13
115
10.7 Ball/Ball
Tangential
Standard Design
116859-13
230
6.8
Ball/Ball
Tangential
Standard Design
117123-00
230
6.8
Ball/Ball
Tangential
Standard Design
