62
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
Thru-Flow Vacuum Motors
Vacuum Motors
5.7" Tangential - Two Stage
7.2" Tangential - Two Stage
7.2" Three Stage
7.5" Two Stage
7.5" Three Stage
7.2" & 7.5" Diameter - "Lamb - Ametek" Vaccum Motors
Brushless "Infin-A-Tek" By-Pass Vacuum Motors
Typical Applications :
Central Vacuums, Carwash Vacuums, Commercial/Industrial Vacuum systems, Steam
Carpet Cleaners
Peripheral Discharge
Peripheral Discharge
Brushless
Tangential Discharge
Part #
Volts Amps Bearings Discharge
Comments
116119-00
115
12.6
Ball/Ball Tangential
Standard Design
117511-00
115
12.7 Ball/Ball
Peripheral
Redesign
116118-00
115
12.8
Ball/Ball
Peripheral Air Sealed Bearing Protection, Epoxy Coated Fan Case
117507-00
115
13.0
Ball/Ball
Tangential
“Long Life” Design, Replaces 116507-00
116137
115
13.0 Ball/Ball
Peripheral
Old Style
117507-13
115
13.8
Ball/Ball Tangential
“Long Life” Design, Air Sealed Bearing Protection, Epoxy
Coated Fan Case, Replaces 116507-13
116103-00
115
13.8
Ball/Ball
Tangential Air Sealed Bearing Protection, Epoxy Coated Fan Case
117500-12
115
15.5 Ball/Ball
Tangential
Premier Design
116139
220
6.7 Ball/Ball
Peripheral
Old Style
116136-00
220
6.8 Ball/Ball Tangential
Old Style
116154-00
220
6.8 Ball/Ball Tangential
Old Style
Part #
Volts Amps Bearings Discharge
Comments
114786
115
10.4 Ball/Ball
Peripheral
Heavy Duty Construction
114788
220
5.0 Ball/Ball
Peripheral
Heavy Duty Construction
Part #
Volts Amps Bearings Discharge
Comments
121101-13
115
9.0 Ball/Ball Tangential
Brushless, High Efficiency
121102-13
230
4.7 Ball/Ball Tangential
Brushless, High Efficiency
Part #
Volts Amps Bearings Discharge
Comments
121113-01
115
10.0 Ball/Ball Tangential
Brushless, High Efficiency
121114-01
230
5.3 Ball/Ball Tangential
Brushless, High Efficiency
Part #
Volts Amps Bearings Discharge
Comments
114787
120
11.0 Ball/Ball
Peripheral
Heavy Duty Construction
114789
220
5.3 Ball/Ball
Peripheral
Heavy Duty Construction
7.2" Motor
7.5" Motor
