60
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
Vacuum Motors
Part #
Volts Amps Bearings Discharge
Comments
116325-00
115
5.6 Ball/Sleeve Peripheral
Standard Design
116520-50
115
5.8 Ball/Sleeve Tangential
Standard Design
116299-00
120
5.8 Ball/Sleeve Peripheral
Standard Design
116196-00
115
7.0 Ball/Sleeve Peripheral
“High Airflow” Design
115977
230
3.8 Ball/Sleeve Peripheral
“High Airflow” Design
116340-00
230
3.8 Ball/Sleeve Peripheral
“High Airflow” Design
Single Stage
Two Stage
Part #
Volts Amps Bearings Discharge
Comments
116155-00
24 VDC
14.4 Ball/Ball
Peripheral
Air Sealed Bearing Protection, Epoxy Coated Fan Case
116157-00
24 VDC
14.4 Ball/Ball
Tangential
Air Sealed Bearing Protection, Epoxy Coated Fan Case
115460
24 VDC
14.8 Ball/Ball
Peripheral
Standard Design
116156-00
36 VDC
10.8 Ball/Ball
Peripheral
Air Sealed Bearing Protection, Epoxy Coated Fan Case
116158-00
36 VDC
10.8 Ball/Ball
Tangential
Air Sealed Bearing Protection, Epoxy Coated Fan Case
116409-13
36 VDC
13.0 Ball/Ball
Tangential
Standard Design
116158-01
36 VDC
17.5 Ball/Ball
Tangential
Standard Design
116406-13
115
15.1 Ball/Ball
Peripheral
Air Sealed Bearing Protection, Epoxy Coated Fan Case
116757-13
115
7.9
Ball/Ball
Peripheral
Low Noise “Acustek” Design, Epoxy Coated Fan Case, Air
Sealed Bearing
116336-00
115
8.0 Ball/Sleeve Peripheral
Standard Design, Replaces 115757
116336-01
115
8.0
Ball/Ball
Peripheral
Standard Design
116392-00
115
8.0
Ball/Ball
Tangential
Air Sealed Bearing Protection, Epox Coated Fan Case,
Replaces 115894
116392-01
115
8.6
Ball/Ball
Tangential
Standard Design
116212-00
115
9.1
Ball/Ball
Peripheral
Epoxy Coated Fan Case
116114-00
115
9.1
Ball/Ball
Tangential
Air Sealed Bearing Protection, Epoxy Coated Fan Case
116207-00
115
9.1
Ball/Ball
Tangential
Epoxy Coated Fan Case
115909
115
9.1
Ball/Ball
Tangential
Air Sealed Bearing Protection, Epoxy Coated Fan Case
116758-13
115
9.1
Ball/Ball
Peripheral
Low Noise “Acustek” Design, Epoxy Coated Fan Case, Air
Sealed Bearing
119407-13
115
10.7 Ball/Ball
Tangential
Standard Design
116763-13
115
11.3 Ball/Ball
Peripheral
Low Noise "Acoustek" Design
116471-00
115
11.7 Ball/Ball
Peripheral
Standard Design
116472-13
115
11.7 Ball/Ball
Tangential
Standard Design
116472-00
115
11.7 Ball/Ball
Tangential
Standard Design
117100-00
115
12.0 Ball/Ball
Tangential
Standard Design
119631-00
115
14.5 Ball/Ball
Tangential
Air watts Series
116125-00
230
3.3 Ball/Sleeve Peripheral
Standard Design
119405-00
230
3.4
Ball/Ball
Peripheral
Standard Design
116213-00
230
4.6
Ball/Ball
Tangential
Epoxy Coated Fan Case
116420-13
230
4.4
Ball/Ball
Tangential
Air Sealed Bearing Protection, Epoxy Coated Fan Case
116549-13
230
5.9
Ball/Ball
Peripheral
Low Noise "Acoustek" Design
5.7" Diameter - "Lamb - Ametek" Vacuum Motors
Typical Applications :
Utility Vacuums, Commercial Vacuums, Carwash Vacuums, Steam Carpet Cleaners
Peripheral Discharge
Tangential Discharge
By-Pass Vacuum Motors
