Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
Blower Motors
Blower Motors
208/230/460/575 Volt - Ball Bearing
Part # HP Amps
Volts
RPM Rotation Body Shaft
Comment
Fig.
T2530
1/3
2.20 208/230/460 1/1140 REV.
8.50 1.2"x1/2"
LIEBERT
1
T2532
1/2
2.40 208/230/460 3/1140 REV.
1.00 5.0"x5/8"
CLIMATE MASTER, DUNHAM BUSH W/
VOLTAGE CHANGE DEVICE
2
T1532
1/2
3.00 200/230/460 1/1140 REV.
9.20 3.5"x1/2"
CARRIER HD44ML460,HD44SX651,
R3433A212
3
T2533
1/2
1.00
575 3/1140 REV.
1.00 5.0"x5/8"
W/ VOLTAGE CHANGE DEVICE 2
T2534
3/4
3.20 208/230/460 1/1140 REV.
8.60 5.0"x5/8"K
UE H567, HD45SX660, FC3076,WWG
3M496, 1817, GE K378
2
T1534
3/4
4.00 200/230/460 1/1140 REV.
11.00 4.0"x5/8"
HD44SX660,
HD46SX660,VL330,HD46VL331,
24-16498-000
3
T2531
3/4
4.00 208/230/460 1/1100 REV.
8.00 3.0"x5/8"
MARATHON K456
1
T2535
3/4
1.40
575 1/1140 REV.
8.10 3.0"x5/8"
LIEBERT 1C16992P1,CMS LCFM575 1
T1536
3/4
1.50
575 1/1140
REV.
11.00 4.0"x5/8"
KEEPRITE 106670,R3443A312
3
T2538
1
4.00 208/230/460 3/1140
REV.
1.00 5.0"x5/8"
KEEPRITE, YORK, TRANE,CARRIER,
LENNOX
2
T2537
1
5.30 208/230/460 1/850
REV.
11.10 5.0"x5/8"
BLANCHARD NESS, HUSSMANN
W/ VOLTAGE CHANGE DEVICE
2
T1538
1
5.60 200/230/460 1/1140
REV.
11.50 4.0"x5/8"
KEEPRITE 170518, 105062,106669,
502595, R3453A212
2
T2540
1
1.70
575 1/1140
REV.
9.10 5.0"x5/8"
KEEPRITE, YORK, TRANE,CARRIER,
LENNOX
2
T2539
1
2.10
575
1/850
REV.
11.10 5.0"x5/8"
BLANCHARD NESS, HUSSMANN,
W/ VOLTAGE CHANGE DEVICE
2
T1540
1
2.30
575 1/1140
REV.
11.50 4.0"x5/8"
KEEPRITE 170517, 105063,R3453A312 3
T1826
1-1/4
5.00 208/230 1/1100
REV.
9.50 3.0"x5/8"
KEEPRITE 1043397-001
(VERTICAL MOUNT)
4
T1946
1-1/4
2.00
575 1/1100
REV.
9.50 3.0"x5/8"
KEEPRITE REFRIGERATION
1043299-001
4
T2542
1-1/2
5.50 208/230/460 1/1140
REV.
10.10 5.0"x5/8"
CARRIER HD54SX680, WWG 3N470AO
SMITH FC3156
2
T1542
1-1/2
5.80 200/230/460 1/1140
REV.
11.50 4.0"x5/8"
CARRIER HD54SX680, R1463A222
KEEPRITE 107002, 107108,
3
T2543
1-1/2
2.20 575 1/1140
REV.
9.50 5.0"x5/8"K
KEEPRITE, YORK, CARRIER,LENNOX,
TRANE MOT1590
3
T2544
2
7.20 208/230/460 1/1140
REV.
11.10 5.0"x5/8"
CANCOIL W/ VOLTAGE CHANGE
DEVICE
2
T2536
2
2.70 575 1/1140
C.W.
11.10 5.0"x5/8"
CANCOIL W/ VOLTAGE CHANGE
DEVICE
2
56 Frame Direct Drive Motors
Fig.1
T2530
T2531
T2535
Fig.2
T2532
T2534
T2533
T2537
T2539
T2538
T2540
T2542
T2544
T2536
Fig.3
T1532
T1534
T1536
T1540
T1542
T2543
Fig.4
T1826
T1946
Three Phase
