Butt’s Pumps and Motors - page 1569

78
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Blowers
Duct Boosters
Duct Boosters
Economical and reliable automatic on/off control for in-line
duct booster fans.
• Mounts on duct or wall to control ambient room temperature.
• Adjustable temperature range: 45° F (7° C) to 110° F (43° C)
and differential.
• 6' Grounded cord.
• Year round use, ON/ OFF, AUTO heating and AUTO cooling .
• Controls various devices, including alarms, heat lamps, lights,
louvers, etc.
Plug-In Switch - Thermostatically Controlled
Part #
Description
Volts
Dimensions
Weight
T9-DS45110
5 Amp maximum load (replaceable 5A fuse).
115 5.50" × 3.25" × 2.25" 1.25 lbs.
Duct Thermostat
T9-DS45110
illustrated
Entreeair® Door Frame Fan
The T9-DF100 is a safe, efficient
and effective way to gently circulate
warm or cool air from room to room.
Door Frame Fan
Part #
Description Volts Amps CFM Weight
T9-DF100
7" Grill diameter.
115 0.35 100 CFM. 2.0 lbs.
Door Frame Fan
T9-DF100
illustrated
• Quiet operation.
• Simple installation.
• In-line ON/OFF power switch.
• 10' Cord.
• Patented design.
Equalizer® Register Booster
T9-EQ2 boosts airflow to problem areas for the
comfort your family deserves. T9-EQ2 uses
a powerful yet quiet fan to pull extra air out of
weak registers, increasing airflow by up to 80%.
Register Air Booster
Register Air Booster
Part #
Dimensions Volts Amps Weight
T9-EQ2
12" × 6-¼" × 3¼" 115 0.35 2.25 lbs.
T9-EQ2
Manual - On/Off
Auto - Heat/Cool
(Adjustable thermostat & sensitivity differential)
• Place and plug convenience.
• Boosts heating and air condi-
tioning.
• 6' Cord w/ 2 prong plug.
• Fits over floor or wall registers
up to 6" × 12".
• Ultra quiet operation.
• White polymeric grills can be painted to match
decor.
• Telescoping housing (Galvanized steel ) installs in
frame walls from 3½" to 6½" thick.
• 10' Grounded cord.
1 Year
Limited
Warranty
ThruWall Fans
Part #
Features
Description Volts Amps
CFM
dBa Weight
T9-TW8-2
• 3 Position, 2 Speed switch
Grill 9.75"
Housing 7 5/8" dia.
115 0.85
160 CFM low spd
200 CFM high spd.
High: 55
Low: 49
5.0 lbs.
T9-TW208
• Built-in solid state speed control allows
for fan speed & sound level control.
• 360° Rotating grill allows airflow
direction to be changed.
Front: 12.5"×10"
Back: 9.75" dia.
Housing: 8" dia.
115 1.0
100 CFM low spd
200 CFM high spd.
High: 55
Low: 49
5.0 lbs.
ThruWall RoomTo Room Fans
The T9-TW8-2 and T9-TW208 ThruWall™ fans
easily install in an interior wall to move heated or
cooled air from one adjoining room to another,
providing year round comfort.
1 Year
Limited
Warranty
T9-TW8-2
T9-TW208
Plug-In Duct Stat
The T9-DS45110
duct stat simplifies
installation of in-line
duct booster fans by
eliminating electrical
connections at the
furnace.
Thru The Wall Fans
