82
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from
hub face to shaft end
OEM
OEM Replacement Motors
OEM Replacement Motors
Blanchard Ness
(cont. from previous page)
Fig.4
Fig.5
Fig.6
Fig.7
Fig.8
Bohn
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R326
1/125
1/1550
115
0.50
CW SP 3.3"
1.94"
1.4" × 1/4"
79101
2
R511
1/100
1/1350
230
0.35
CW SP 3.3"
1.70"
2.0" × 1/4"
79105, 79115
3
R605
1/55
1/2800
120
1.0
CW SP Skel
0.96" 1.75" × 0.1811"
79103, 79104
4
R306
1/50
1/1550
115
0.65
CW SP 3.3"
2.92"
1.1" × 1/4"
79102, 79114
5
R130
1/45
1/1550
230
0.80
CW SP 3.3"
2.70"
1.5" × 5/16"
79106, 79108,
79113, 5001M
2
R332
1/25
1/1550
115
1.50
CW SP 3.3"
2.69"
1.5" × 5/16"
79107,112,
5001F,11S,20F
3
R318
1/20
1/1550
115
1.60
CW SP 3.3"
2.75"
2.8" × 5/16"
79105, 5010S
2
R358
1/20
1/1550
115
2.00 CCW SP 3.3"
3.25"
2.8" × 5/16"
5001L, 8S, 4L
6
R359
1/20
1/1550 208/230 1.20 CCW SP 3.3"
3.25"
2.8" × 5/16"
5008T, 5034M 6
R313
1/15
1/1550
115
2.10 CCW SP
3.3"
3.50"
3.0"×5/16"
5034LS, 5008SS,
U-572
7
R314
1/15
1/1550 208/230 1.30 CCW SP 3.3"
3.50"
3" × 5/16"
5044MS, 5008TS,
U-573
7
S1502
1/3
1/1075
200/230
/460
1.40
Rev 5/440 5.5"
7.30"
3.5" × 1/2"
5015H
8
S1504
1/2
1/1075
200/230
/460
4.00
Rev 7.5/440 5.5" 12.20"
3.5" × 1/2"
5002P, 5003P
8
T1532
1/2
1/1140
200/230
/460
1.50
Rev 3 Ph 5.5"
9.20"
3.5" × 1/2"
Condenser Fan
8
T2537
1
1/850
208/230
/460
5.30
Rev 3 Ph 6.5" 11.10"
5" × 5/8"
E5028
1
T2539
1
1/850
575
2.10
Rev 3 Ph 6.5" 11.10"
5" × 5/8"
E5027
1
Fig.3
Fig.1
Fig.2
Part #
HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
T2537
1
1/850 208/230 5.30
Rev 3 Ph 6.5" 11.10"
5" × 5/8"
E05026
1
T2537
1
1/850
460
5.30
Rev 3 Ph 6.5" 11.10"
5" × 5/8"
E05028
1
T2539
1
1/850
575
2.10
Rev 3 Ph 6.5" 11.10"
5" × 5/8"
E05027
1
T2544
2
1/1140
208/230
/460
7.20
Rev 3 Ph 6.5" 11.10"
5" × 5/8"
E05033
1
T2536
2
1/1140
575
2.70
CW 3 Ph 6.5" 11.10"
5" × 5/8"
E05034
1
Also See Bohn
Also See Blanchard
