Butt’s Pumps and Motors - page 1570

79
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from
hub face to shaft end
OEM
OEM Replacement Motors
OEM Replacement Motors
Air 2000
Addison-
Comfortaire
Acorn Woodstoves
Part #
HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R316
1/20
1550
115
1.40 CCW SP 3.3"
2.7"
-
HRV Motor
3
Part #
HP Spd/RPM Volts Amps Rot
Type Dia Body Shaft
Comment
Fig
R22442
1/4
2/1075 208/230 1.30 R.P.
5/370 5.5"
4.3"
6.0" x 1/2"
Cond. Fan
2
R22187
1/2
1/1075 208/230 2.80 R.P.
10/370 5.5"
5.2"
6.0"x 1/2"
Cond. Fan
2
R22016
1/2
2/1075 208/230 2.80 R.P.
10/370 5.5"
5.2"
6.0"x 1/2"
Cond. Fan
2
R32716
1/2
2/1075
460
2.00 REV.
10/370 5.5"
5.5"
6.4" x 1/2"
Cond. Fan
2
Part #
HP Spd/RPM Volts Amps Rot
Type Dia Body Shaft
Comment
Fig
R250
1/65
2/1550
115
0.50 CCW SP
3.3"
3.7"
Hubless
605850M0
1
Airdex
Part #
HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
RB245
1/25
1550
115
1.50 CCW SP 3.3"
9.2"
-
AMV245
4
Air King
Airtemp
Part #
HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R503
1/130
1/1550
115
0.40 CW S.P.
3.3"
1.90"
2.4"×1/4"
2108375001
5
R603
1/125
1/3000
115
0.58 CW S.P.
Skel
0.62"
2.7"×7/32"
2108370033
6
R206
1/80
2/1550
115
0.50 CW S.P.
3.3"
1.90"
1.5"×1/4"
Vent Fan
5
R222
1/75
1/1550
115
0.70 CCW S.P.
3.3"
2.00"
1.2"×1/4"
2108375025
5
R415
1/65
1/1550
115
0.78 CCW S.P.
3.3"
2.90"
2.3"×1/4"×2.3"
2108375034
7
R201
1/50
1/1550
115
0.90 CW S.P.
3.3"
1.90"
2.2"×1/4"
2108375036
5
Part #
HP Spd/RPM Volts Amps Rot
Type Dia Body Shaft
Comment
Fig
R760
1/8
3/1100
115
1.30 CW PSC/12.5/370 5.5" 3.6" 2.0"×1/2"×2.8"
3525153
8
R22002
1/6
1/1075 208/230 1.30 CW PSC/4/370 5.5" 3.5"
3.0"×1/2"
3775858
8
R52287
1/3
3/1310 208/230 2.90 CW PSC/5/370 5.5" 4.5" 2.5"×1/2"×3.0"
Fasco D808
8
Fig.1
Fig.6
Fig.8
Fig.7
Fig.2
Fig.3
Fig.4
Fig.5
