86
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from
hub face to shaft end
OEM
OEM Replacement Motors
OEM Replacement Motors
Carrier
Cont...
Part #
HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
S1502
1/3
1/1075
208/230
460
2.80
Rev
5/440
5.5" 7.3"
3.5"×1/2"
Condenser Fan
1
R32712
1/3
2/1075
460
1.10
Rev
5/370
5.5" 4.7"
6.4"×1/2"
Condenser Fan
2
R22015
1/3
2/1075 208/230 1.80
R.P.
7.5/370
5.5" 4.8"
6.0"×1/2"
Condenser Fan
2
R42415
1/3
4/1050
115
10.20 CCW
SP
5.5" 4.4"
4.6"×1/2"
BDP
3
R42310
1/3
4/1075
115
6.40
Rev
5/370
5.5" 4.8"
6.0"×1/2"
HC41SE117,
P251-2307, 06
4
R42237
1/3
4/1075 208/230 4.80
Rev
10/440
5.5" 5.3"
6.0"×1/2"
HC41SE651 HC39SE651 4
R31718
1/2
1/1050
460
0.90
R.P.
10/370
5.5" 5.3"
3.3"×1/2"
Blower Motor
2
S1506
1/2
1/1075
575
1.50
Rev
7.5/440
5.5" 9.2"
3.5"×1/2
Condenser Fan
1
S1504
1/2
1/1075
200/230
460
3.20
Rev
7.5/440
5.5" 9.2"
3.5"×1/2"
Condenser Fan
1
R22017
1/2
1/1075 208/230 4.00 CCW
7.5/370
5.5" 7.4"
4.5"×1/2"
HC44SL230
3
S1507A
1/2
1/1075
200/230
460
4.60
Rev
7.5/440
5.5" 6.3"
2.9"×1/2"
Condenser Fan
1
R42575
1/2
1/1140
575
1.00
Rev
3 PH
5.5" 7.9"
2.5"×1/2"
HD44ML461
5
T1532
1/2
1/1140
200/230
460
3.00
Rev
3 PH
5.5" 9.2"
3.5"×1/2"
Condenser Fan
1
R32716
1/2
2/1075
460
2.00
Rev
10/370
5.5" 5.5"
6.4"×1/2"
Condenser Fan
2
R52294
1/2
3/1075 208/230 3.20 CCW
7.5/370
5.5" 5.5"
7.0"×1/2"×2.8"
HC43CE230,
5KCP39MGB2
6
Fig.4
Fig.5
Fig.6
Fig.3
Fig.1
Fig.2
