OEM
OEM Replacement Motors
OEM Replacement Motors
Part #
HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
S1510
3/4
1/1075
200/230
460
4.60
Rev
20/370
5.5" 10.8"
3.5"×1/2"
Condenser Fan
1
T1534
3/4
1/1140
200/230
460
4.00
Rev
3 PH
5.5" 11.0"
4.0"×5/8 KF 3 Phase Condenser Fan 1
S1174
3/4
1/1725
115/208
230
11.60 Rev
PSC/INC
5.5" 10.6"
2.0"×5/8" K
HC46DX610, 615
2
R42257
3/4
4/1075 208/230 5.40
R.P.
10/440
5.5" 5.5"
6.0"×1/2"
HC45SE651, P251-5701 3
R42241
3/4
4/1075
115
11.50 Rev
15/370
5.5" 7.3"
2.9"×1/2"
HC45SA114, P251-2702 7
R32050
3/4
3/1025
575
1.65
Rev
15/370
5.5" 6.5"
4.0"×1/2"
Commercial Rooftop 4
R32051
3/4
3/1075
460
2.15
Rev
15/370
5.5" 6.6"
4.0"×1/2"
HC45AL460
4
S1455
1
1/1075
575
2.10 CCW
30/370
5.5" 10.2"
3.5"×5/8" KF
Condenser Fan
1
S1453
1
1/1075
200/230
460
6.50 CCW
30/370
5.5" 10.2"
3.5"×5/8" KF
Condenser Fan
1
S1514
1
1/1075
200/230
460
6.40
Rev
25/370
5.5" 11.5"
4.0"×5/8"
HC51TE200
1
T2538
1
1/1140
208/230
460
6.60
Rev
3 PH
6.5" 11.1"
5.0"×5/8" KF
HD52VE214
5
R42242
1
3/1000 208/230 6.20
Rev
25/370
5.5" 7.3"
4.0"×5/8"
HC52AL230, 231, 232,
HC52SE208
3
T2156
2
1/3450
208/230
460
5.20
Rev
3 PH
6.5" 11.6"
2.0"×5/8"
Condenser Fan
6
T2166
3
1/1750
208/230
460
8.20
Rev
3 PH
6.5" 12.6"
2.3"×7/8" K
Condenser Fan
6
T2164
3
1/3450
208/230
460
8.00
Rev
3 PH
6.5" 11.8"
2.3"×5/8" K
Condenser Fan
6
H980
3
1/1725
208/230
460
10.60 Rev
3 PH
6.5" 14.9"
2.3"×7/8"
HD60FK651
7
H979
5
1/1725
208/230
460
15.00 Rev
3 PH
6.5" 15.9"
2.3"×7/8"
HD60FK652
8
T2168
5
1/3450
208/230
460
13.00 Rev
3 PH
6.5" 11.9"
2.3"×7/8"
HD60AZ660
6
Fig.7
Fig.8
Fig.6
Carrier
Cont...
Fig.1
Fig.4
Fig.5
Fig.2
Fig.3
