Buck Stove
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R1138
1/50
3/1550
115
0.88 CCW SP 3.9"
4.00"
2.5"×5/16"
R22CCW270ZD,
7136-6045, 7163-5967
4
R1139
1/50
3/1550
115
0.88 CCW SP 3.3"
2.80 2.5"×5/16"×1.12"
R22CW206MD 5
Caloritech
Part #
HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R210
1/50
1/1550
230
0.40 CCW
3.3"
2.40"
1.5"×1/4"
eLEC. HEATERS 6
R217
1/35
1/1450
230
0.50
CW
3.3"
2.40"
1.2"×1/4"
ELEC. HEATERS 6
R213
1/25
1/1550
115
1.40 CCW
3.3"
3.10"
1.7"×5/16"
ELEC. HEATERS 7
R303
1/25
1/1550
115
1.40 CCW
3.3"
3.84"
3.3"×5/16"
ELEC. HEATERS 7
Broan
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R611
1/300
1/1500
115
0.55
CW SP Skel
0.55"
1.7"×0.181"
3008001, 23303
1
R603
1/125
1/2400
115
0.52
CW SP Skel
0.65"
2.2"×7/32"
81058,96, 81795,
81826,27, 81993,94,
82230
1
R601
1/80
1/3000
115
0.70
CW SP Skel
0.90"
2.2"×1/4"
30080007,162
1
R322
1/60
1/1550
115
0.80
CW SP 3.3"
2.00
1.3"×1/4"
30080111,112
2
R610
1/60
2/2400
115
1.00
CW SP Skel
0.90"
1.2"×7/32"
30080011,12, 51000,
52000
1
R605
1/55
1/2800
115
0.90
CW SP Skel
0.90"
1.7"×0.181"
Vent Fan
1
R467
1/25
1/1550
115
1.40
CW SP 3.3"
3.10" 1.8"×5/16"×1.8"
30080059,30080060 2
R2343
1/9
1/1050
115
3.20 CCW SP 5.0"
2.90"
2.6"×1/2"
1094343
3
Fig.1
Fig.4
Fig.5
Fig.6
Fig.7
Fig.3
Fig.2
