Butt’s Pumps and Motors - page 1572

81
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from
hub face to shaft end
OEM
OEM Replacement Motors
OEM Replacement Motors
Part #
HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R326
1/125
1/1550
115
0.50
CW SP 3.3"
1.94"
1.4" × 1/4"
E01001,2,3
2
R511
1/100
1/1350
230
0.28
CW SP 3.3"
2.10"
2.0"×1/4"
79105,79115
3
R302
1/100
1/1550
230
0.30
CW SP 3.3"
1.94"
1.3" × 1/4"
E01004
3
R1014
1/65
1/3000
115
0.70
CW SP Skel
0.87"
1.25"×0.1811"
E1014, J238-087-8104 4
R605
1/55
1/2800
115
0.90
CW SP Skel
0.90"
1.7"×0.1811"
E310131, 79103
4
R130
1/25
1/1550
230
0.80
CW SP 3.3"
2.72"
1.5"×5/16"
79106, 108, 113
2
R318
1/25
1/1550
115
1.50
CW SP 3.3"
2.80"
2.8"×5/16"
79105 , E1007
2
R358
1/20
1/1550
115
2.00 CCW SP 3.3"
3.25"
2.8" × 5/16"
E01007,57,58
5
R359
1/20
1/1550 208/230 1.20 CCW SP 3.3"
3.25"
2.8" × 5/16"
E01059
5
R1052
1/20
1/1550
115
2.00 CCW SP 3.3"
3.0"
2.8"× 5/16"
E1052
6
R1053
1/20
1/1550 208/230 1.00 CCW SP 3.3"
3.0"
2.8"× 5/16"
E1053
6
R22445
1/4
1/825 208/230 1.90
Rev 5/370 5.5"
4.90"
6.0"×1/2"
E1026
7
S1502
1/3
1/1075
208/230
/460
2.80
Rev 5/440 5.5"
7.30"
3.5"×1/2"
5015H
8
R22748
1/3
1/1075 208/230 2.60
Rev 5/370 5.5"
4.30"
6.0"×1/2"
E1022, E1025
7
R22745
1/2
1/1075 208/230 4.40
Rev 5/370 5.5"
4.80"
6.0"×1/2"
E1064
7
S1504
1/2
1/1075
208/230
/460
3.20
Rev 7.5/370 5.5"
9.2"
3.5"×1/2"
E1063,64
8
T1532
1/2
1/1140
208/230
/460
3.00
Rev 3 PH 5.5"
9.2"
3.5"×1/2"
Cond. Fan
8
T2532
1/2
3/1140
208/230
/460
2.70
Rev 3 Ph 6.5"
8.1"
5" × 5/8"
E01020, 1066
9
T2533
1/2
3/1140
575
1.00
Rev 3 Ph 6.5"
8.1"
5" × 5/8"
E01021
9
T1536
3/4
1/1140
575
1.50
Rev 3 PH 5.5"
11.0"
4.0"×5/8" kf
E1021,24, E5026,28 8
T1538
1
1/1140
208/230
/460
5.60
Rev 3 PH 5.5"
11.5"
4.0"×5/8" kf
Air Conditioner
8
Fig.1
Fig.3
Fig.5
Fig.4
Fig.7
Fig.8
Fig.9
Fig.6
Fig.2
Blanchard Ness
(cont. next page...)
Belding
Part #
HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R756
1/12
3/1080
115
1.30 CCW 5/370 5.5"
3.5"
2.0"×1/2"×2.2" R.A.C M8/M10 Chassis 1
R62160
1/3
3/1365 208/230 2.80 CCW 3/370 5.5"
4.4"
2.9"×1/2"×4.3"
R.A.C. 1
Also See Bohn
