USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
Submersible Effluent Pumps
3
B
Professional Plumbing
11/04
Testing is performed with
water specific gravity of 1.0
@ 68˚F (20˚C), other fluids
may vary performance
Series EP72X
3/4" Spherical Solids Handling
Manual & Automatic
Series: EP72X
3/4HP, 3450RPM, 60Hz
DISCHARGE ...................................
1½” NPT, Female, Vertical
LIQUID TEMPERATURE ................
104°F (40°C) Continuous
MOTOR HOUSING ............................
Cast Iron
BODY & STRAINER .........................
Thermoplastic
IMPELLER:
Design
......................
10 Vane vortex, with pump out vanes on back
side. Balanced, ISO G6.3
Material
.....................
Cast Iron
SHAFT
..............................................
Stainless Steel
O-RINGS
..................................
Buna-N
HARDWARE ......................................
300 Series Stainless Steel
PAINT .................................................
Air Dry Enamel
SEAL:
Design
.......................
Single Mechanical, Type 21
Material
......................
Silicon Carbide/Silicon Carbide/Buna-N
Hardware -300 Series Stainless
CORD ENTRY....................................
20 ft. (6m) Quick connect cord with plug and
pressure gromment for sealing and strain relief
UPPER BEARING..............................
Single Row, Ball, Oil Lubricated
LOWER BEARING.............................
Single Row, Ball, Oil Lubricated
MOTOR:
Design
.......................
Oil Filled
Insulation
....................
Class B
SINGLE PHASE.................................
Permanent Split Capacitor (PSC).
Includes thermal overload protection in motor
LEVEL CONTROL
EP72X ........................ None
EP72AX...................... Wide angle, Mechanical, 20 ft. (6m) cord
with PIggy-Back plug
EP72VFX ................... Vertical float, PVC, snap action, 20 ft. (6m) cord
with PIggy-Back plug
MINUMUM SUMP DIA:
EP72AX...................... 18" (457mm)
EP72X & EP72VXF.... 12" (305mm)
DESCRIPTION:
PUMP IS DESIGNED FOR HANDLING SEWAGE
EFFLUENT IN TYPICAL SEPTIC TANK/EFFLUENT
APPLICATIONS
CSA 108
UL 778
LR16567
C US
