Submersible Effluent Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
6
B
Professional Plumbing
Series EHV
3/4" Spherical Solids Handling
Manual & Automatic
6/10
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
LENGTH
CORD
SIZE
CORD
TYPE
EHV412
101298 0.5
115/1
60 3450
H
6.4
19.6
20 ft. (6m)
14/3 SJTOW
EHV412A
103542 0.5
115/1
60 3450
H
6.4
19.6
20 ft. (6m)
14/3 SJTOW
EHV412VF
101300 0.5
115/1
60 3450
H
6.4
19.6
20 ft. (6m)
14/3 SJTOW
EHV412AT
103543 0.5
115/1
60 3450
H
6.4
19.6
20 ft. (6m)
14/3 SJTOW
EHV412
101298G 0.5
115/1
60 3450
H
6.4
19.6
30 ft. (9m)
14/3 SJTOW
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION II HAZARDOUS LOCATIONS.
3.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION I HAZARDOUS LOCATIONS.
4.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
inches
(mm)
EHV412A
EHV412 (Less Float
EHV412AT (Attached to Motor Housing)
EHV412VF
